53RAD Series
Manufacturer: Bourns Inc.
Beta
⌘K
POT 1M OHM 1W CERMET LINEAR
| Part | Actuator Length [x] | Actuator Length [x] | Size - Body [y] | Size - Body [x] | Size - Body [y] | Size - Body [x] | Actuator Type | Rotation | Mounting Type | Number of Gangs | Taper | Resistive Material | Built in Switch | Resistance (Ohms) | Temperature Coefficient | Tolerance | Features | Number of Turns | Power (Watts) | Actuator Diameter [diameter] | Actuator Diameter [diameter] | Termination Style | Adjustment Type | Bushing Thread | Bushing Thread | Power (Watts) | Resistance (Ohms) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Bourns Inc. | 22 mm | 0.866 in | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | Slotted | 290 ° | Panel Mount | 1 | Linear | Cermet | None | 1 MΩ | 150 ppm/°C | 10 % | Sealed | 1 | 1 W | 6 mm | 0.236 in | Solder Lug | User Defined | M10 | 0.75 | ||
Bourns Inc. | 16 mm | 0.63 in | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | Slotted | 290 ° | Panel Mount | 1 | Linear | Conductive Plastic | None | 1000 ppm/°C | 20 % | Sealed | 1 | 0.5 W | 6 mm | 0.236 in | Solder Lug | User Defined | M10 | 0.75 | 0.5 W | 1k | |
Bourns Inc. | 25 mm | 0.984 in | 0.492 " | 0.521 " | 12.5 mm | 13.25 mm | Slotted | 290 ° | Panel Mount | 1 | Logarithmic | Conductive Plastic | None | 1000 ppm/°C | 20 % | Sealed | 1 | 0.25 W | 6 mm | 0.236 in | Solder Lug | User Defined | M10 | 0.75 | 0.25 W | 10k |
