172-E09 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 9POS PNL MNT
| Part | Color | Contact Material | Wire Gauge [Min] | Wire Gauge [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Mounting Type | Number of Rows [custom] | Connector Style | Current Rating (Amps) | Material Flammability Rating | Number of Positions | Flange Feature | Contact Finish | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Type | Contact Finish Thickness | Connector Type | Features | Shell Material, Finish | Termination | Primary Material | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | White | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Panel Mount | 2 | D-Sub | 5 A | UL94 V-0 | 9 | 4-40 | Gold | Steel | Yellow Chromate Plated | 1 | DE E | Signal | Flash | Plug Male Pins | ||||||
 NorComp Inc. | White | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Panel Mount | 2 | D-Sub | 5 A | UL94 V-0 | 9 | 4-40 | Gold | 1 | DE E | Signal | Flash | Plug Male Pins | Grounding Indents | Nickel Plated Steel | ||||||
 NorComp Inc. | White | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Panel Mount Through Hole | 2 | D-Sub | 5 A | UL94 V-0 | 9 | Board Side (4-40) | Gold | 1 | DE E | Signal | Flash | Receptacle Female Sockets | Solder | ||||||||||
 NorComp Inc. | White | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Panel Mount | 2 | D-Sub | 5 A | UL94 V-0 | 9 | 4-40 | Gold | Steel | Yellow Chromate Plated | 1 | DE E | Signal | Flash | Receptacle Female Sockets | ||||||
 NorComp Inc. | White | Brass | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | Panel Mount Through Hole | 2 | D-Sub | 5 A | UL94 V-0 | 9 | Housing/Shell (Unthreaded) | Gold | 1 | DE E | Signal | Flash | Plug Male Pins | Grounding Indents | Nickel Plated Steel | Solder | |||||||
NorComp Inc. | Black | Brass | 125 °C | -55 C | Polyamide (PA6T) Nylon 6T | Free Hanging (In-Line) | 2 | D-Sub | 5 A | UL94 V-0 | 9 | Board Side (4-40) | Gold | 1 | DE E | Signal | Receptacle Female Sockets | Metal | 30 Áin | 0.76 Ám | ||||||||
 NorComp Inc. | White | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Panel Mount | 2 | D-Sub | 5 A | UL94 V-0 | 9 | 4-40 | Gold | 1 | DE E | Signal | Flash | Plug Male Pins | Grounding Indents | |||||||
 NorComp Inc. | White | Brass | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | Panel Mount Through Hole | 2 | D-Sub | 5 A | UL94 V-0 | 9 | Board Side (4-40) | Gold | Steel | Yellow Chromate Plated | 1 | DE E | Signal | Flash | Plug Male Pins | Solder | |||||||
NorComp Inc. | White | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Panel Mount Through Hole | 2 | D-Sub | 5 A | UL94 V-0 | 9 | Board Side (4-40) Mating Side Female Screwlock (4-40) | Gold | 1 | DE E | Signal | Flash | Receptacle Female Sockets | Board Lock | Solder | |||||||||
 NorComp Inc. | White | Brass | 19.5 AWG | 26 AWG | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Panel Mount | 2 | D-Sub | 5 A | UL94 V-0 | 9 | Cable Side (4-40) | Gold | 1 | DE E | Signal | Flash | Receptacle Female Sockets | Nickel Plated Steel |
