DLCBS Series

Catalog

BRD SPT SNAP LOCK NYLON 20MM

Part	Features	Holding Type	Between Board Height	Between Board Height	Mounting Type	Support Hole Diameter	Support Hole Diameter	Support Hole Diameter	Mounting Hole Diameter	Mounting Hole Diameter	Mounting Hole Diameter	Support Panel Thickness [Max]	Support Panel Thickness [Min]	Support Panel Thickness [Max]	Support Panel Thickness [Min]	Mounting Panel Thickness [Max]	Mounting Panel Thickness [Min]	Mounting Panel Thickness [Max]	Mounting Panel Thickness [Min]	Length - Overall [x]	Length - Overall [x]	Material	Between Board Height	Mounting Panel Thickness [Min]	Mounting Panel Thickness [Max]	Support Panel Thickness [Max]	Between Board Height [z]	Between Board Height [z]	Length - Overall	Length - Overall	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]	Mounting Hole Diameter [diameter]
Essentra Components DLCBSHD-20M-01	Winged	Snap Lock	20 mm	0.787 "	Snap Lock	0.25 "	6.35 mm	0.25 "	6.35 mm	0.25 in	0.25 "	0.087 in	0.79 mm	2.2 mm	0.031 in	2.2 mm	0.031 in	0.087 in	0.79 mm	37.6 mm	1.48 in	Nylon
Essentra Components DLCBS-8-01	Winged	Snap Lock	12.7 mm	0.5 in	Snap Lock	0.156 in	3.96 mm	5 32"	0.15625 in	0.156 in	3.96 mm	0.078 in	0.79 mm		0.031 in		0.79 mm	1.98 mm		29.5 mm	1.161 in	Nylon	0.5 in	0.031 in	0.078 "	1.98 mm
Essentra Components DLCBS-10-01	Winged	Snap Lock	15.88 mm	0.625 in	Snap Lock	0.156 in	3.96 mm	5 32"	0.15625 in	0.156 in	3.96 mm	0.078 in	0.79 mm		0.031 in		0.79 mm	1.98 mm		32.7 mm	1.287 in	Nylon	5 8	0.031 in	0.078 "	1.98 mm
Essentra Components DLCBSHD-25M-19	Winged	Snap Lock	25 mm	0.984 in	Snap Lock	0.25 "	6.35 mm	0.25 "	6.35 mm	0.25 in	0.25 "	0.087 in	0.79 mm	2.2 mm	0.031 in	2.2 mm	0.031 in	0.087 in	0.79 mm	42.6 mm	1.677 in	Nylon
Essentra Components DLCBSHD-10M-01	Winged	Snap Lock			Snap Lock	0.25 "	6.35 mm	0.25 "	6.35 mm	0.25 in	0.25 "	0.087 in	0.79 mm	2.2 mm	0.031 in	2.2 mm	0.031 in	0.087 in	0.79 mm			Nylon					0.394 in	10 mm	27.6 mm	1.087 in
Essentra Components DLCBS4-4-01	Winged	Snap Lock	6.1 mm	0.24 in	Snap Lock	0.156 in	3.96 mm	5 32"				0.078 in	1.3 mm	1.98 mm	0.051 in		0.79 mm	1.98 mm		21.1 mm	0.831 in	Nylon		0.031 in	0.078 "						0.1875 in	0.187 in	4.75 mm
Essentra Components DLCBS-14-01	Winged	Snap Lock	22.23 mm	0.875 in	Snap Lock	0.156 in	3.96 mm	5 32"	0.15625 in	0.156 in	3.96 mm	0.078 in	0.79 mm		0.031 in		0.79 mm	1.98 mm				Nylon	0.875 in	0.031 in	0.078 "	1.98 mm			39 mm	1.535 "
Essentra Components DLCBS4-5-01	Winged	Snap Lock	9.1 mm	0.358 in	Snap Lock	0.156 in	3.96 mm	5 32"				0.078 in	1.3 mm	1.98 mm	0.051 in		0.79 mm	1.98 mm		24 mm	0.945 "	Nylon		0.031 in	0.078 "						0.1875 in	0.187 in	4.75 mm
Essentra Components DLCBS4-8-01	Winged	Snap Lock	18.8 mm	0.74 "	Snap Lock	0.156 in	3.96 mm	5 32"				0.078 in	1.3 mm	1.98 mm	0.051 in		0.79 mm	1.98 mm		33.8 mm	1.331 in	Nylon		0.031 in	0.078 "						0.1875 in	0.187 in	4.75 mm
Essentra Components DLCBS-12-19	Winged	Snap Lock	19.05 mm	0.75 "	Snap Lock	0.156 in	3.96 mm	5 32"	0.15625 in	0.156 in	3.96 mm	0.078 in	0.79 mm		0.031 in		0.79 mm	1.98 mm				Nylon	0.75 "	0.031 in	0.078 "	1.98 mm			35.9 mm	1.413 in
