630-5W5 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 5POS R/A SLDR
| Part | Dielectric Material | Contact Material | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Color | Connector Type | Contact Finish | Contact Type | Flange Feature | Contact Finish Thickness | Contact Finish Thickness | Shell Material, Finish | Number of Rows | Material Flammability Rating | Current Rating (Amps) | Connector Style | Termination | Mounting Type | Features | Backset Spacing | Backset Spacing | Number of Positions | Shell Size, Connector Layout [x] | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout | Contact Finish Thickness | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Power | Housing/Shell (Unthreaded) | 30 Áin | 0.76 Ám | Nickel Plated Steel | 1 | UL94 V-0 | 30 A | Combo D-Sub | Solder | Right Angle Through Hole | Shielded | 0.52 " | 13.2 mm | 5 | 3 | DB B | 5W5 | ||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Coax | Housing/Shell (M3) | 1 | UL94 V-0 | Combo D-Sub | Solder | Right Angle Through Hole | Board Lock Mounting Brackets | 0.37 in | 9.4 mm | 5 | 3 | DB B | 5W5 | Flash | |||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Power | Housing/Shell (M3) | 30 Áin | 0.76 Ám | 1 | UL94 V-0 | 10 A | Combo D-Sub | Solder | Right Angle Through Hole | Mounting Brackets | 0.52 " | 13.2 mm | 5 | 3 | DB B | 5W5 | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Power | Housing/Shell (M3) | 30 Áin | 0.76 Ám | Nickel Plated Steel | 1 | UL94 V-0 | 20 A | Combo D-Sub | Solder | Right Angle Through Hole | Board Lock Mounting Brackets | 0.52 " | 13.2 mm | 5 | 3 | DB B | 5W5 | ||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Coax | Housing/Shell | Nickel Plated Steel | 1 | UL94 V-0 | Combo D-Sub | Solder | Right Angle Through Hole | Mounting Brackets | 0.37 in | 9.4 mm | 5 | 3 | DB B | 5W5 | Flash | 4-40 | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Power | 4-40 | 30 Áin | 0.76 Ám | 1 | UL94 V-0 | 40 A | Combo D-Sub | Solder | Right Angle Through Hole | Board Lock | 0.52 " | 13.2 mm | 5 | 3 | DB B | 5W5 | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Power | M3 | Nickel Plated Steel | 1 | UL94 V-0 | 10 A | Combo D-Sub | Solder | Right Angle Through Hole | Mounting Brackets | 0.52 " | 13.2 mm | 5 | 3 | DB B | 5W5 | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Power | 4-40 | 1 | UL94 V-0 | 40 A | Combo D-Sub | Solder | Right Angle Through Hole | Board Lock Mounting Brackets | 0.52 " | 13.2 mm | 5 | 3 | DB B | 5W5 | Flash | ||||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Power | 4-40 | Nickel Plated Steel | 1 | UL94 V-0 | 20 A | Combo D-Sub | Solder | Right Angle Through Hole | Board Lock | 0.52 " | 13.2 mm | 5 | 3 | DB B | 5W5 | Flash | |||
 EDAC Inc. | Polyester Thermoplastic | Copper Alloy | 125 VDC | -55 C | 125 °C | Black | Receptacle Female Sockets | Gold | Power | Housing/Shell (Unthreaded) | 1 | UL94 V-0 | 40 A | Combo D-Sub | Solder | Right Angle Through Hole | Shielded | 0.52 " | 13.2 mm | 5 | 3 | DB B | 5W5 | Flash |
