LY1-0-T Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
RELAY GEN PURPOSE SPDT 15A 24V
| Part | Operate Time | Release Time | Contact Rating (Current) | Must Operate Voltage | Coil Resistance | Switching Voltage | Termination Style | Contact Material | Coil Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Coil Type | Load - Max Switching | Coil Current | Relay Type | Must Release Voltage | Approval Agency | Contact Form | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | 25 ms | 25 ms | 15 A | 19.2 VDC | 650 Ohms | 125 VDC 250 VAC | PC Pin | Silver Alloy | 24 VDC | 55 °C | -25 °C | Non Latching | 1875 W 3750 VA | 36.9 mA | General Purpose | 2.4 VDC | CE CSA TUV UR | SPDT (1 Form C) | Through Hole |
