EDS12 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

SWITCH: DIP-SWITCH; POLES NUMBER: 12; OFF-ON; 0.025A/24VDC; POS: 2

Part	Body Material	Mechanical Life	Electrical Life	Length	Length	Termination Style	Height Above Board	Height Above Board	Number of Positions	Circuit	Voltage Rating	Actuator Level	Actuator Type	Contact Material	Pitch	Pitch	Contact Finish	Current Rating (Amps)	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Height Above Board [z]	Height Above Board [z]
TE Connectivity AMP Connectors EDS12SGRNTR04Q	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	30.38 mm	1.196 in	Gull Wing	3.4 mm	0.134 in	12	SPST	24 VDC	Flush Recessed	Slide (Standard)	Copper Alloy	2.54 mm	0.1 "	Gold	25 mA	Surface Mount	85 °C	-20 ░C
TE Connectivity AMP Connectors EDS12SNRNTU04Q	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	30.38 mm	1.196 in	J Lead	3.45 mm	0.136 "	12	SPST	24 VDC	Flush Recessed	Slide (Standard)	Copper Alloy	2.54 mm	0.1 "	Gold	25 mA	Surface Mount	85 °C	-20 ░C
TE Connectivity AMP Connectors EDS12SGNNTU04Q	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	30.38 mm	1.196 in	Gull Wing	3.8 mm	0.15 in	12	SPST	24 VDC	Raised	Slide (Standard)	Copper Alloy	2.54 mm	0.1 "	Gold	25 mA	Surface Mount	85 °C	-20 ░C
TE Connectivity AMP Connectors EDS12SGRSTU04Q	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	30.38 mm	1.196 in	Gull Wing	3.4 mm	0.134 in	12	SPST	24 VDC	Flush Recessed	Slide (Standard)	Copper Alloy	2.54 mm	0.1 "	Gold	25 mA	Surface Mount	85 °C	-20 ░C
TE Connectivity AMP Connectors EDS12SNRNTR04Q	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	30.38 mm	1.196 in	J Lead	3.45 mm	0.136 "	12	SPST	24 VDC	Flush Recessed	Slide (Standard)	Copper Alloy	2.54 mm	0.1 "	Gold	25 mA	Surface Mount	85 °C	-20 ░C
TE Connectivity AMP Connectors EDS12SNNNTR04Q	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	30.38 mm	1.196 in	J Lead			12	SPST	24 VDC	Raised	Slide (Standard)	Copper Alloy	2.54 mm	0.1 "	Gold	25 mA	Surface Mount	85 °C	-20 ░C	3.85 mm	0.152 in
TE Connectivity AMP Connectors EDS12SNRSTU04Q	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	30.38 mm	1.196 in	J Lead	3.45 mm	0.136 "	12	SPST	24 VDC	Flush Recessed	Slide (Standard)	Copper Alloy	2.54 mm	0.1 "	Gold	25 mA	Surface Mount	85 °C	-20 ░C
TE Connectivity AMP Connectors EDS12SNRSTR04Q	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	30.38 mm	1.196 in	J Lead	3.45 mm	0.136 "	12	SPST	24 VDC	Flush Recessed	Slide (Standard)	Copper Alloy	2.54 mm	0.1 "	Gold	25 mA	Surface Mount	85 °C	-20 ░C
TE Connectivity AMP Connectors EDS12SNNNTU04Q	Polyamide (PA) Nylon	2000 Cycles	2000 Steps	30.38 mm	1.196 in	J Lead			12	SPST	24 VDC	Raised	Slide (Standard)	Copper Alloy	2.54 mm	0.1 "	Gold	25 mA	Surface Mount	85 °C	-20 ░C	3.85 mm	0.152 in
