794624 Series

Catalog

CONN HEADER SMD R/A 20POS 3MM

Part	Applications	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions Loaded	Contact Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Insulation Height	Insulation Height	Material Flammability Rating	Voltage Rating	Connector Type	Current Rating (Amps)	Row Spacing - Mating	Row Spacing - Mating	Termination	Style	Number of Positions	Shrouding	Contact Finish - Post	Mounting Type	Insulation Material	Contact Type	Pitch - Mating	Pitch - Mating	Features	Insulation Color	Number of Rows [custom]	Operating Temperature [Min]	Operating Temperature [Max]	Fastening Type	Contact Shape
TE Connectivity AMP Connectors 5-794624-0	General Purpose	2.54 µm	100 µin	All	Brass	100 çin	2.54 çm	0.29 in	7.37 mm	UL94 V-0	250 V	Header	Varies by Wire Gauge	0.118 in	3 mm	Solder	Board to Cable/Wire	20	Shrouded - 4 Wall	Tin	Right Angle Surface Mount	Nylon Polyamide (PA)	Male Pin	3 mm	0.118 in	Board Lock	Black	2	-40 C	105 ░C	Locking Ramp	Square
TE Connectivity AMP Connectors 5-794624-4	General Purpose	2.54 µm	100 µin	All	Brass	100 çin	2.54 çm	0.29 in	7.37 mm	UL94 V-0	250 V	Header	Varies by Wire Gauge	0.118 in	3 mm	Solder	Board to Cable/Wire	24	Shrouded - 4 Wall	Tin	Right Angle Surface Mount	Nylon Polyamide (PA)	Male Pin	3 mm	0.118 in	Board Lock	Black	2	-40 C	105 ░C	Locking Ramp	Square
