CRE22F4D Series
Manufacturer: ZF Electronics
Beta
⌘K
SWITCH ROCKER SPST 20A 125V
| Part | Electrical Life | Mechanical Life | Panel Cutout Dimensions [x] | Panel Cutout Dimensions [y] | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Voltage Rating - AC | Switch Function | Actuator Type | Features | Actuator Marking | Termination Style | Color - Actuator/Cap | Circuit | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ZF Electronics | 6000 Cycles | 100000 Cycles | 28.5 mm | 12.1 mm | 85 °C | -20 ░C | 20 A | 125 V | On-Off | Concave (Curved) | Two-Tone Rocker | ON OFF | Quick Connect - 0.250" (6.3mm) | Black Red | SPST | Panel Mount Snap-In |
