ATA016 Series
Manufacturer: OmniOn Power™
Beta
⌘K
DC DC CONVERTER 0.8-5.5V 88W
| Part | Type | Package / Case | Features | Voltage - Input (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input (Min) [Min] | Applications | Control Features | Power (Watts) | Voltage - Output 1 [Min] [custom] | Voltage - Output 1 [Max] [custom] | Number of Outputs | Efficiency | Current - Output (Max) [Max] | Mounting Type | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 OmniOn Power™ | Non-Isolated PoL Module | 7-SMD Module | OCP OTP Remote On/Off UVLO | 14 V | 85 °C | -40 C | 8.3 V | ITE (Commercial) | Active Low Enable | 88 W | 0.8 V | 5.5 V | 1 | 92 % | 16 A | Surface Mount | 33 mm | 13.5 mm | 0.53 in | 1.3 in | 0.33 in | 8.3 mm |
