307-052 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 52POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Pitch | Pitch | Read Out | Gender | Termination | Color | Number of Rows [custom] | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Contact Finish | Contact Type | Number of Positions/Bay/Row | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Solder | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Through Hole | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Solder Wire Wrap | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Right Angle Through Hole | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Solder | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Solder | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Solder Wire Wrap | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Right Angle Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Solder | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Through Hole | |||||
 EDAC Inc. | 2 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Wire Wrap | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Solder | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Right Angle Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Solder | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Gold | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Card Extender | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Dual | Female | Solder | Green | 2 | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Tin | Semi Bellows | 26 | 52 | -40 C | 105 ░C | Board Edge Straddle Mount |
