333-040 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, DUAL SIDE, 1.57 MM, 40 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
| Part | Material - Insulation | Termination Rows [custom] | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Contact Material | Mounting Type | Termination | Pitch | Pitch | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Number of Positions | Gender | Card Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Color | Contact Finish | Number of Positions/Bay/Row | Termination Rows | Number of Rows | Number of Positions/Bay/Row [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Through Hole | Wire Wrap | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Dual | 40 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Green | Gold | 20 Bay/Row | ||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Through Hole | Wire Wrap | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Single | 40 | Female | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Green | Gold | 1 | 1 | 40 | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Through Hole | Wire Wrap | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Dual | 40 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Green | Gold | 20 Bay/Row | ||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Through Hole | Solder | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Single | 40 | Female | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Green | Gold | 1 | 1 | 40 | ||||
 EDAC Inc. | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Through Hole | Solder | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Single | 40 | Female | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | Green | Gold | 1 | 1 | 40 | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Through Hole | Solder | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Dual | 40 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Green | Gold | 20 Bay/Row | |||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Through Hole | Solder Eyelet(s) | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Dual | 40 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Green | Gold | 20 Bay/Row | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Board Edge Straddle Mount | Solder Eyelet(s) | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Dual | 40 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | Green | Gold | 20 Bay/Row | Card Extender | ||||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Through Hole | Solder | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Dual | 40 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Green | Gold | 20 Bay/Row | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | Copper Alloy | Board Edge Straddle Mount | Solder | 3.96 mm | 0.156 in | Cantilever | -40 C | 105 ░C | Dual | 40 | Female | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | Green | Gold | 20 Bay/Row | Card Extender |
