896-008 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 8POS 0.125
| Part | Material - Insulation | Termination Rows | Read Out | Card Type | Contact Material | Mounting Type | Color | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Contact Type | Number of Positions | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Termination | Contact Finish | Gender | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Through Hole | Black | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Wire Wrap | Gold | Female | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Right Angle Through Hole | Black | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Solder | Gold | Female | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Through Hole | Black | Flush Mount Side Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Wire Wrap | Gold | Female | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Wire Wrap | Gold | Female | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Through Hole | Black | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Solder | Gold | Female | 0.156 " | 3.96 mm |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Through Hole | Black | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Solder | Gold | Female | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Through Hole | Black | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Solder | Gold | Female | 0.156 " | 3.96 mm |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Right Angle Through Hole | Black | 4-40 Flush Mount Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Solder | Gold | Female | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Through Hole | Black | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Wire Wrap | Gold | Female | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Single | Non Specified - Single Edge | Copper Alloy | Right Angle Through Hole | Black | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Cantilever | 8 | 125 °C | -40 C | 8 | 0.25 Ám | 10 Áin | 1 | Solder | Gold | Female | 0.128 " | 3.25 mm |
