PKB.M1 Series
Manufacturer: LEMO
Beta
⌘K
CIRCULAR PUSH PULL CONNECTORS RECPT (CDB)14CTS
| Part | Color | Ingress Protection | Orientation | Insert Material | Number of Positions | Shell Size - Insert | Fastening Type | Shell Material | Contact Finish - Mating | Connector Type | Current Rating (Amps) | Mounting Feature | Primary Material | Shielding | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Mounting Type | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LEMO | Gray | IP50 | B | Polyetheretherketone (PEEK) | 14 | M14 | Detent Lock Push-Pull | Polysulfone (PSU) | Gold | Receptacle Female Sockets | 2 A | Front and Rear Side Nut | Plastic | Unshielded | 150 °C | -50 °C | Automotive Industrial Medical Testing Equipment & Measurement | ||
LEMO | Gray | IP50 | B | Polyetheretherketone (PEEK) | 10 | M10 | Detent Lock Push-Pull | Polysulfone (PSU) | Gold | Receptacle Female Sockets | 3 A | Front and Rear Side Nut | Plastic | Unshielded | 150 °C | -50 °C | Automotive Industrial Medical Testing Equipment & Measurement | Panel Mount Right Angle Through Hole | Solder |
LEMO | Gray Green | IP50 | B | Polyetheretherketone (PEEK) | 14 | M14 | Detent Lock Push-Pull | Polysulfone (PSU) | Gold | Receptacle Female Sockets | 2 A | Front and Rear Side Nut | Plastic | Unshielded | 150 °C | -50 °C | Automotive Industrial Medical Testing Equipment & Measurement | ||
LEMO | Gray | IP50 | B | Polyetheretherketone (PEEK) | 14 | M14 | Detent Lock Push-Pull | Polyetherimide (PEI) | Gold | Receptacle Female Sockets | 2 A | Front and Rear Side Nut | Plastic | Unshielded | 170 °C | -50 °C | Automotive Industrial Medical Testing Equipment & Measurement | Panel Mount Through Hole | Solder |
LEMO | Black | IP50 | B | Polyetheretherketone (PEEK) | 10 | M10 | Detent Lock Push-Pull | Polyetherimide (PEI) | Gold | Receptacle Female Sockets | 3 A | Front and Rear Side Nut | Plastic | Unshielded | 170 °C | -50 °C | Automotive Industrial Medical Testing Equipment & Measurement | Panel Mount Through Hole | Solder |
LEMO | Gray | IP50 | B | Polyetheretherketone (PEEK) | 10 | M10 | Detent Lock Push-Pull | Polyetherimide (PEI) | Gold | Receptacle Female Sockets | 3 A | Front and Rear Side Nut | Plastic | Unshielded | 170 °C | -50 °C | Automotive Industrial Medical Testing Equipment & Measurement | Panel Mount Through Hole | Solder |
