LRSA Series
Rack Mount Power Supplies Power 480W Output 12/15VDC Input 90-264VAC
Manufacturer: EOS Power India Private Ltd
Catalog
Rack Mount Power Supplies Power 480W Output 12/15VDC Input 90-264VAC
Beta
⌘K
Rack Mount Power Supplies Power 480W Output 12/15VDC Input 90-264VAC
Rack Mount Power Supplies Power 480W Output 12/15VDC Input 90-264VAC
Rack Mount Power Supplies Power 480W Output 12/15VDC Input 90-264VAC
| Part | Standard Number | Features | Efficiency | Current - Output 1 | Voltage - Output 1 | Applications | Voltage - Output 2 | Type | Approval Agency | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Current - Output 2 | Power (Watts) | Voltage - Isolation | Number of Outputs | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Voltage - Input [Min] | Voltage - Input [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EOS Power India Private Ltd | 62368-1 | Adjustable Output Hot Swappable Load Sharing PFC Remote On/Off Universal Input | 92 % | 24 A | 30 V | ITE (Commercial) | 30 V | Enclosed | CE cCSAus | -40 °C | 71 °C | Rack Mount | 24 A | 1440 W | 3000 V | 2 | 435.8 mm | 10.35 " | 17.16 " | 5.22 in | 132.6 mm | 263 mm | 90 VAC | 264 VAC |
 EOS Power India Private Ltd | 62368-1 | Adjustable Output Hot Swappable Load Sharing PFC Remote On/Off Universal Input | 92 % | 10 A | 24 V | ITE (Commercial) | 30 V | Enclosed | CE cCSAus | -40 °C | 71 °C | Rack Mount | 8 A | 480 W | 3000 V | 2 | 435.8 mm | 10.35 " | 17.16 " | 5.22 in | 132.6 mm | 263 mm | 90 VAC | 264 VAC |
EOS Power India Private Ltd | 62368-1 | Adjustable Output Hot Swappable Load Sharing PFC Remote On/Off Universal Input | 92 % | 20 A | 12 V | ITE (Commercial) | 15 V | Enclosed | CE cCSAus | -40 °C | 71 °C | Rack Mount | 16 A | 480 W | 3000 V | 2 | 435.8 mm | 10.35 " | 17.16 " | 5.22 in | 132.6 mm | 263 mm | 90 VAC | 264 VAC |
