ASJ-145 Series
Manufacturer: Adam Tech
Beta
⌘K
AUDIO JACK
| Part | Body Color | Mating Length/Depth | Mating Length/Depth | Contact Material | Current Rating (Amps) | Housing Material | Contact Material - Plating | Voltage - Rated | Insulation Color | Connector Type | Actual Diameter [diameter] | Actual Diameter [diameter] | Internal Switch(s) | Signal Lines | Termination | Number of Positions/Contacts [custom] | Number of Positions/Contacts [custom] | Mounting Type | Shielding | Features | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Industry Recognized Mating Diameter [diameter] | Industry Recognized Mating Diameter [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | Black | 11 mm | 0.433 in | Phosphor Bronze | 0.5 A | Thermoplastic | Gold | 30 V | Black | Phone Jack | 2.6 mm | 0.102 in | Single Switch | Stereo (4 Conductor TRRS) | Solder | 5 | 4 | Right Angle Surface Mount | Unshielded | Board Guide | Female | -20 ░C | 70 °C | 2.5 mm | 0.098 " |
 Adam Tech | Black | 11 mm | 0.433 in | Phosphor Bronze | 0.5 A | Thermoplastic | Gold | 30 V | Black | Phone Jack | 2.6 mm | 0.102 in | Two Switches | Stereo (4 Conductor TRRS) | Solder | 6 | 4 | Right Angle Surface Mount | Unshielded | Board Guide | Female | -20 ░C | 70 °C | 2.5 mm | 0.098 " |
