306-035 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 70POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions | Flange Feature | Mounting Type | Card Type | Gender | Card Thickness [Max] | Card Thickness [Min] | Color | Contact Material | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Number of Rows [custom] | Termination | Read Out | Pitch | Pitch | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | 4-40 Flush Mount Threaded Insert Top Opening | Panel Mount | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder Eyelet(s) | Dual | 3.96 mm | 0.156 in | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | Flush Mount Top Opening Unthreaded | Panel Mount | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder Eyelet(s) | Dual | 3.96 mm | 0.156 in | 0.156 " | 3.96 mm | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | 4-40 Flush Mount Threaded Insert Top Opening | Panel Mount | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder Eyelet(s) | Dual | 3.96 mm | 0.156 in | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | Flush Mount M3 Threaded Insert Top Opening | Panel Mount Through Hole | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder | Dual | 3.96 mm | 0.156 in | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | Through Hole | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder | Dual | 3.96 mm | 0.156 in | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | 4-40 Flush Mount Threaded Insert Top Opening | Panel Mount Through Hole | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder | Dual | 3.96 mm | 0.156 in | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | 4-40 Flush Mount Threaded Insert Top Opening | Panel Mount Through Hole | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder | Dual | 3.96 mm | 0.156 in | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | 4-40 Flush Mount Threaded Insert Top Opening | Panel Mount Through Hole | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder | Dual | 3.96 mm | 0.156 in | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | 4-40 Flush Mount Threaded Insert Top Opening | Panel Mount | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder Eyelet(s) | Dual | 3.96 mm | 0.156 in | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 70 | Floating Bobbin Flush Mount | Panel Mount Through Hole | Non Specified - Dual Edge | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Copper Alloy | Cantilever | 0.25 Ám | 10 Áin | Gold | -40 C | 105 ░C | 35 | 2 | Solder | Dual | 3.96 mm | 0.156 in | 0.116 " | 2.95 mm |
