D09P24 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
DSUB STR STB 9 PIN
| Part | Number of Positions | Dielectric Material | Color | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) | Contact Type | Contact Finish | Connector Type | Voltage Rating | Flange Feature | Features | Material Flammability Rating | Connector Style | Mounting Type | Termination | Number of Rows | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Shell Material, Finish | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol ICC (FCI) | 9 | Polybutylene Terephthalate (PBT) | Black | DE E | 1 | 0.76 Ám | 30 Áin | 5 A | Signal | Gold | Male Pins Plug | 300 VDC | Housing/Shell (4-40) | Board Lock Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder | 2 | Phosphor Bronze | -55 °C | 125 °C | |||
Amphenol ICC (FCI) | 9 | Polybutylene Terephthalate (PBT) | Black | DE E | 1 | 5 A | Signal | Gold | Male Pins Plug | 300 VDC | Housing/Shell (4-40) | Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder | 2 | Phosphor Bronze | -55 °C | 125 °C | Flash | ||||
Amphenol ICC (FCI) | 9 | Polybutylene Terephthalate (PBT) | Black | DE E | 1 | 5 A | Signal | Gold | Male Pins Plug | 300 VDC | Housing/Shell (Unthreaded) | Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder | 2 | Phosphor Bronze | -55 °C | 125 °C | Flash | ||||
Amphenol ICC (FCI) | 9 | Polybutylene Terephthalate (PBT) | Black | DE E | 1 | 0.76 Ám | 30 Áin | 5 A | Signal | Gold | Male Pins Plug | 300 VDC | Female Screwlock (M3) Mating Side | Board Lock Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder | 2 | Brass | -55 °C | 125 °C | |||
 Amphenol ICC (FCI) | 9 | Polybutylene Terephthalate (PBT) | Black | DE E | 1 | 5 A | Signal | Gold | Male Pins Plug | 300 VDC | Female Screwlock (4-40) Mating Side | Board Lock Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder | 2 | Phosphor Bronze | -55 °C | 125 °C | Flash | Steel Tin-Nickel Plated | |||
 Amphenol ICC (FCI) | 9 | Polybutylene Terephthalate (PBT) | Black | DE E | 1 | 5 A | Signal | Gold | Male Pins Plug | 300 VDC | Housing/Shell (4-40) | Board Lock Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder | 2 | Phosphor Bronze | -55 °C | 125 °C | Flash | Steel Tin-Nickel Plated | |||
Amphenol ICC (FCI) | 9 | Liquid Crystal Polymer (LCP) Glass Filled | Black | DE E | 1 | 5 A | Signal | Gold | Male Pins Plug | 300 VDC | Housing/Shell (4-40) | Board Guide Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder Paste | 2 | Copper Alloy | Nickel Plated Steel | -55 °C | |||||
 Amphenol ICC (FCI) | 9 | Liquid Crystal Polymer (LCP) Glass Filled | Black | DE E | 1 | 0.76 Ám | 30 Áin | 5 A | Signal | Gold | Male Pins Plug | 300 VDC | Housing/Shell (4-40) | Board Guide Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder Paste | 2 | Copper Alloy | Nickel Plated Steel | -55 °C | |||
 Amphenol ICC (FCI) | 9 | Polybutylene Terephthalate (PBT) | Black | DE E | 1 | 0.76 Ám | 30 Áin | 5 A | Signal | Gold or Gold GXT™ | Male Pins Plug | 300 VDC | Female Screwlock (4-40) Mating Side | Board Lock Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder | 2 | Phosphor Bronze | -55 °C | 125 °C | Steel Tin-Nickel Plated | ||
Amphenol ICC (FCI) | 9 | Polybutylene Terephthalate (PBT) | Black | DE E | 1 | 0.76 Ám | 30 Áin | 5 A | Signal | Gold | Male Pins Plug | 300 VDC | Housing/Shell (Unthreaded) | Grounding Indents | UL94 V-0 | D-Sub | Through Hole | Solder | 2 | Phosphor Bronze | -55 °C | 125 °C |
