20LPCV Series
Manufacturer: Sensata-Crydom
Beta
⌘K
SSR RELAY SPST-NO 25A 20-300V
| Part | Termination Style | Termination Style | Operating Temperature [Max] | Operating Temperature [Min] | Output Type | Package / Case | Voltage - Load [Min] | Voltage - Load [Max] | Load Current | Mounting Type | Voltage - Input [Min] | Voltage - Input [Max] | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sensata-Crydom | 0.25 in 6.3 mm | Screw Terminal Quick Connect | 80 °C | -30 ░C | AC Proportional Control | Module | 20 V | 300 V | 25 A | Chassis Mount | 4 mA | 20 mA | CE |
Sensata-Crydom | 0.25 in 6.3 mm | Screw Terminal Quick Connect | 80 °C | -30 ░C | AC Proportional Control | Module | 20 V | 300 V | 40 A | Chassis Mount | 4 mA | 20 mA | CE |
Sensata-Crydom | 0.25 in 6.3 mm | Screw Terminal Quick Connect | 80 °C | -30 ░C | AC Proportional Control | Module | 20 V | 300 V | 15 A | Chassis Mount | 4 mA | 20 mA | CE |
