TUNS700 Series

Catalog

AC/DC CONVERTER 28V 700W

Part	Load Regulation	Line Regulation	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Applications	Features	Voltage - Output 1	Type	Efficiency	Number of Outputs	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Standard Number	Approval Agency	Power (Watts)	Current - Output (Max) [Max]
Cosel USA, Inc. TUNS700F28	56 mV	56 mV	Through Hole	-40 °C	100 °C	7-DIP Module	ITE (Commercial)	Universal Input	28 V	Enclosed	89 %	1	117.3 mm	4.62 in	2.42 in	61.5 mm	0.5 in	12.7 mm	60950-1 62368-1	CE CSA cURus TUV UL	700 W	25 A
Cosel USA, Inc. TUNS700F28-P	56 mV	56 mV	Through Hole	-40 °C	100 °C	7-DIP Module	ITE (Commercial)	Baseplate Universal Input	28 V	Enclosed	89 %	1	117.3 mm	4.62 in	2.42 in	61.5 mm	0.5 in	12.7 mm	60950-1 62368-1	CE CSA cURus TUV UL	700 W	25 A
Cosel USA, Inc. TUNS700F48-P	96 mV	96 mV	Through Hole	-40 °C	100 °C	7-DIP Module	ITE (Commercial)	Baseplate Universal Input	48 V	Enclosed	90 %	1	117.3 mm	4.62 in	2.42 in	61.5 mm	0.5 in	12.7 mm	60950-1 62368-1	CE CSA cURus TUV UL	701 W	14.6 A
Cosel USA, Inc. TUNS700F12-P	24 mV	24 mV	Through Hole	-40 °C	100 °C	7-DIP Module	ITE (Commercial)	Baseplate Universal Input	12 V	Enclosed	86 %	1	117.3 mm	4.62 in	2.42 in	61.5 mm	0.5 in	12.7 mm	60950-1 62368-1	CE CSA cURus TUV UL	701 W	58.4 A
Cosel USA, Inc. TUNS700F48	96 mV	96 mV	Through Hole	-40 °C	100 °C	7-DIP Module	ITE (Commercial)	Universal Input	48 V	Enclosed	90 %	1	117.3 mm	4.62 in	2.42 in	61.5 mm	0.5 in	12.7 mm	60950-1 62368-1	CE CSA cURus TUV UL	700 W	14.6 A
Cosel USA, Inc. TUNS700F12	24 mV	24 mV	Through Hole	-40 °C	100 °C	7-DIP Module	ITE (Commercial)	Universal Input	12 V	Enclosed	86 %	1	117.3 mm	4.62 in	2.42 in	61.5 mm	0.5 in	12.7 mm	60950-1 62368-1	CE CSA cURus TUV UL	700 W	58.4 A
