P5020 Series

Manufacturer: Freescale Semiconductor - NXP

Catalog

IC MPU QORIQ P5 2.0GHZ 1295BGA

Part	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Supplier Device Package	Supplier Device Package [y]	Supplier Device Package [x]	Co-Processors/DSP	SATA	Security Features	Number of Cores/Bus Width	USB	Ethernet	RAM Controllers	Speed	Additional Interfaces	Package / Case	Type	Utilized IC / Part	Core Processor	Board Type	Contents
Freescale Semiconductor - NXP P5020NXE7QMB	105 °C	-40 °C	Surface Mount	1295-FCPBGA	37.5	37.5	SEC 4.2 Security	SATA 3Gbps (2)	Boot Security Cryptography Secure Fusebox Secure JTAG Secure Memory Tamper Detection	2 Core 64 Bit	USB 2.0 + PHY (2)	1 Gbps 10 Gbps	DDR3 DDR3L	2 GHz	DUART I2C MMC/SD SPI	1295-BBGA FCBGA
Freescale Semiconductor - NXP P5020NSN7TNB	105 °C	0 °C	Surface Mount	1295-FCPBGA	37.5	37.5		SATA 3Gbps (2)		2 Core 64 Bit	USB 2.0 + PHY (2)	1 Gbps 10 Gbps	DDR3 DDR3L	2 GHz	DUART I2C MMC/SD SPI	1295-BBGA FCBGA
Freescale Semiconductor - NXP P5020DS-PB			Fixed														MPU	P5020	e5500	Evaluation Platform	Board(s)
Freescale Semiconductor - NXP P5020NSN7VNB	105 °C	0 °C	Surface Mount	1295-FCPBGA	37.5	37.5		SATA 3Gbps (2)		2 Core 64 Bit	USB 2.0 + PHY (2)	1 Gbps 10 Gbps	DDR3 DDR3L	2 GHz	DUART I2C MMC/SD SPI	1295-BBGA FCBGA
Freescale Semiconductor - NXP P5020NSE7QMB	105 °C	0 °C	Surface Mount	1295-FCPBGA	37.5	37.5	SEC 4.2 Security	SATA 3Gbps (2)	Boot Security Cryptography Secure Fusebox Secure JTAG Secure Memory Tamper Detection	2 Core 64 Bit	USB 2.0 + PHY (2)	1 Gbps 10 Gbps	DDR3 DDR3L	2 GHz	DUART I2C MMC/SD SPI	1295-BBGA FCBGA
Freescale Semiconductor - NXP P5020NXN7QMB	105 °C	-40 °C	Surface Mount	1295-FCPBGA	37.5	37.5		SATA 3Gbps (2)		2 Core 64 Bit	USB 2.0 + PHY (2)	1 Gbps 10 Gbps	DDR3 DDR3L	2 GHz	DUART I2C MMC/SD SPI	1295-BBGA FCBGA
Freescale Semiconductor - NXP P5020NSE7VNB	105 °C	0 °C	Surface Mount	1295-FCPBGA	37.5	37.5	SEC 4.2 Security	SATA 3Gbps (2)	Boot Security Cryptography Secure Fusebox Secure JTAG Secure Memory Tamper Detection	2 Core 64 Bit	USB 2.0 + PHY (2)	1 Gbps 10 Gbps	DDR3 DDR3L	2 GHz	DUART I2C MMC/SD SPI	1295-BBGA FCBGA
Freescale Semiconductor - NXP P5020NSE7TNB	105 °C	0 °C	Surface Mount	1295-FCPBGA	37.5	37.5	SEC 4.2 Security	SATA 3Gbps (2)	Boot Security Cryptography Secure Fusebox Secure JTAG Secure Memory Tamper Detection	2 Core 64 Bit	USB 2.0 + PHY (2)	1 Gbps 10 Gbps	DDR3 DDR3L	2 GHz	DUART I2C MMC/SD SPI	1295-BBGA FCBGA
