683-009 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 9POS R/A SOLDER
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Color | Connector Type | Contact Type | Number of Positions | Contact Finish Thickness | Contact Finish | Connector Style | Ingress Protection | Mounting Type | Backset Spacing | Backset Spacing | Material Flammability Rating | Termination | Current Rating (Amps) | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Features | Flange Feature | Flange Feature | Shell Material, Finish | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Nylon 9T Polyamide (PA9T) | -55 C | 105 ░C | Brass | Black | Plug Male Pins | Signal | 9 | Flash | Gold | D-Sub | IP66 - Dust Tight Water Resistant | Panel Mount Right Angle Through Hole | 0.59 in | 14.99 mm | UL94 V-0 | Solder | 5 A | 1 | DE E | Ground Strap Grounding Indents | Housing/Shell | 4-40 | Nickel Plated Steel | 2 |
