OQ085 Series
Manufacturer: Amphenol Anytek
Beta
⌘K
OQ - 5.08 - 8P BLACK, LCP THR ,
| Part | Contact Tail Length | Contact Tail Length | Operating Temperature [Min] | Operating Temperature [Max] | Number of Levels | Pitch [x] | Pitch [x] | Color | Housing Material | Type | Contact Mating Finish | Current - UL | Positions Per Level | Header Orientation | Termination Style | Material Flammability Rating | Mounting Type | Number of Positions | Insulation Height | Insulation Height | Voltage - UL | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Anytek | 0.102 in | 2.6 mm | -45 °C | 130 °C | 1 | 0.2 in | 5.08 mm | Black | Liquid Crystal Polymer (LCP) | Header Male Pins Shrouded (4 Side) | Tin | 20 A | 8 | 90° Right Angle | Solder | UL94 V-0 | Through Hole | 8 | 8.61 mm | 0.339 " | 300 V | Copper |
 Amphenol Anytek | 0.102 in | 2.6 mm | -45 °C | 130 °C | 1 | 0.2 in | 5.08 mm | Black | Liquid Crystal Polymer (LCP) | Header Male Pins Shrouded (4 Side) | Tin | 20 A | 8 | Vertical | Solder | UL94 V-0 | Through Hole | 8 | 12 mm | 0.472 in | 300 V | Copper |
