R12442 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMA / SWITCH EDGE CARD SMT TYPE
| Part | Center Contact Plating | Body Material | Voltage Rating | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Connector Style | Contact Termination | Housing Color | Frequency - Max [Max] | Center Contact Material | Impedance | Connector Type | Shield Termination | Mounting Type | Number of Ports | Fastening Type | Body Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | Gold | Brass | 300 VDC | Polyetheretherketone (PEEK) | 85 °C | -40 C | SMA | Solder | Gold Silver | 3 GHz | Beryllium Copper | 50 Ohms | Receptacle Female Socket | Solder | Board Edge Cutout Surface Mount | 1 | Threaded | |
Radiall USA, Inc. | Gold | Brass | 500 V | Polytetrafluoroethylene (PTFE) | 165 °C | -65 ░C | SMA | Solder | Gold | 18 GHz | Beryllium Copper | 50 Ohms | Female Socket Jack | Solder | Board Edge End Launch | 1 | Threaded | Gold |
 Radiall USA, Inc. | Gold | Brass | 500 V | Polytetrafluoroethylene (PTFE) | 165 °C | -65 ░C | SMA | Solder | Gold | 18 GHz | Beryllium Copper | 50 Ohms | Female Socket Jack | Solder | Surface Mount | 1 | Threaded | Gold |
Radiall USA, Inc. | Gold | Brass | 500 V | Polytetrafluoroethylene (PTFE) | 165 °C | -65 ░C | SMA | Solder | Gold | 18 GHz | Beryllium Copper | 50 Ohms | Female Socket Jack | Solder | Surface Mount | 1 | Threaded | Gold |
 Radiall USA, Inc. | Gold | Brass | 500 V | Polytetrafluoroethylene (PTFE) | 165 °C | -65 ░C | SMA | Solder | Gold | 18 GHz | Beryllium Copper | 50 Ohms | Female Socket Jack | Solder | Through Hole | 1 | Threaded | Gold |
Radiall USA, Inc. | Gold | Brass | 500 V | Polytetrafluoroethylene (PTFE) | 165 °C | -65 ░C | SMA | Solder | Silver | 18 GHz | Beryllium Copper | 50 Ohms | Female Socket Jack | Solder | Through Hole | 1 | Threaded | White Bronze |
 Radiall USA, Inc. | Gold | Brass | 500 V | Polytetrafluoroethylene (PTFE) | 165 °C | -65 ░C | SMA | Solder | Gold | 18 GHz | Beryllium Copper | 50 Ohms | Female Socket Jack | Solder | Surface Mount | 1 | Threaded | Gold |
 Radiall USA, Inc. | Gold | Brass | 335 V | Polytetrafluoroethylene (PTFE) | 165 °C | -65 ░C | SMA | Solder | Gold | 18 GHz | Beryllium Copper | 50 Ohms | Female Socket Jack | Solder | Through Hole | 1 | Threaded | Gold |
 Radiall USA, Inc. | Gold | Brass | 500 V | Polytetrafluoroethylene (PTFE) | 165 °C | -65 ░C | SMA | Solder | Gold | 18 GHz | Beryllium Copper | 50 Ohms | Female Socket Jack | Solder | Board Edge End Launch | 1 | Threaded | Gold |
 Radiall USA, Inc. | Gold | Brass | 500 V | Polytetrafluoroethylene (PTFE) | 165 °C | -65 ░C | SMA | Solder | Gold | 18 GHz | Beryllium Copper | 50 Ohms | Female Socket Jack | Solder | Board Edge End Launch | 1 | Threaded | Gold |
