Isolated DC/DC Converters - Through Hole DC-DC Converter, 5 to 6 Watt, 4:1 Input Range, 9-36VDC Input, 15VDC Output, DIP 1.25x0.80x0.40", 3KVDC min. Isolation
Isolated DC/DC Converters - Through Hole DC-DC Converter, 5 to 6 Watt, 4:1 Input Range, 9-36VDC Input, 15VDC Output, DIP 1.25x0.80x0.40", 3KVDC min. Isolation
Isolated DC/DC Converters - Through Hole DC-DC Converter, 5 to 6 Watt, 4:1 Input Range, 9-36VDC Input, 15VDC Output, DIP 1.25x0.80x0.40", 3KVDC min. Isolation
| Part | Voltage - Output 1 | Approval Agency | Number of Outputs | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Input (Max) [Max] | Type | Operating Temperature [Min] | Operating Temperature [Max] | Applications | Voltage - Isolation | Power (Watts) | Package / Case | Features | Current - Output (Max) [Max] | Mounting Type | Voltage - Input (Min) [Min] | Efficiency | Standard Number | Voltage - Output 2 | Current - Output (Max) | Current - Output (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | 12 V | CE | 1 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 72 V | Isolated Module | -40 °C | 85 °C | ITE (Commercial) | 1.5 kV | 5.6 W | 24-DIP Module 14 Leads | SCP | 470 mA | Through Hole | 18 V | |||||
 Cincon Electronics Co. LTD | 15 V | CE | 2 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 36 V | Isolated Module | -40 °C | 100 °C | ITE (Commercial) | 6000 VDC | 6 W | 24-DIP Module 8 Leads | SCP UVLO | Through Hole | 9 V | 84 % | 62368-1 | -15 V | |||
Cincon Electronics Co. LTD | 12 V | CE | 2 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 36 V | Isolated Module | -40 °C | 85 °C | ITE (Commercial) | 500 V | 5.5 W | 24-DIP Module 14 Leads | SCP | Through Hole | 9 V | -12 V | 230 mA | 230 mA | |||
Cincon Electronics Co. LTD | 12 V | CE | 1 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 72 V | Isolated Module | -40 °C | 100 °C | ITE (Commercial) | 6000 VDC | 6 W | 24-DIP Module 8 Leads | SCP UVLO | 500 mA | Through Hole | 18 V | 84 % | 62368-1 | |||
Cincon Electronics Co. LTD | 3.3 V | CE | 1 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 36 V | Isolated Module | -40 °C | 85 °C | ITE (Commercial) | 1.5 kV | 3.3 W | 24-DIP Module 14 Leads | SCP | 1 A | Through Hole | 9 V | 78 % | ||||
Cincon Electronics Co. LTD | 12 V | CE | 2 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 72 V | Isolated Module | -40 °C | 100 °C | ITE (Commercial) | 6000 VDC | 6 W | 24-DIP Module 8 Leads | SCP UVLO | Through Hole | 18 V | 83 % | 62368-1 | -12 V | 250 mA | ||
Cincon Electronics Co. LTD | 12 V | CE | 2 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 72 V | Isolated Module | -40 °C | 85 °C | ITE (Commercial) | 1.5 kV | 5.5 W | 24-DIP Module 14 Leads | SCP | Through Hole | 18 V | 80 % | -12 V | 230 mA | 230 mA | ||
Cincon Electronics Co. LTD | 5 V | CE | 1 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 72 V | Isolated Module | -40 °C | 100 °C | ITE (Commercial) | 6000 VDC | 5 W | 24-DIP Module 8 Leads | SCP UVLO | 1 A | Through Hole | 18 V | 80 % | 62368-1 | |||
Cincon Electronics Co. LTD | 5 V | CE | 1 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 36 V | Isolated Module | -40 °C | 100 °C | ITE (Commercial) | 6000 VDC | 5 W | 24-DIP Module 8 Leads | SCP UVLO | 1 A | Through Hole | 9 V | 80 % | 62368-1 | |||
Cincon Electronics Co. LTD | 5 V | CE | 2 | 0.8 " | 0.4 " | 31.8 mm | 10.2 mm | 20.3 mm | 1.25 in | 72 V | Isolated Module | -40 °C | 85 °C | ITE (Commercial) | 500 V | 5 W | 24-DIP Module 14 Leads | SCP | Through Hole | 18 V | 80 % | -5 V | 500 mA |
