CI0103P1 Series
Manufacturer: Cvilux USA
Beta
⌘K
3 POS 2.00MM(.079) SINGLE ROW ST
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Connector Type | Contact Type | Number of Rows | Contact Finish - Post | Pitch - Mating | Pitch - Mating | Shrouding | Termination | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Shape | Current Rating (Amps) | Fastening Type | Insulation Color | Insulation Material | Contact Material | Contact Length - Post [x] | Contact Length - Post | Insulation Height [z] | Insulation Height [z] | Style | Material Flammability Rating | Mounting Type | Number of Positions Loaded | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cvilux USA | 120 Áin | 3.05 Ám | Header | Male Pin | 1 | Tin | 0.079 " | 2 mm | Shrouded - 4 Wall | Kinked Pin Solder | 120 µin | 3.05 µm | Square | 2 A | Detent Lock | Natural | Halogen Free Nylon 6T Polyamide (PA6T) | Brass | 0.134 " | 3.4 mm | 6.1 mm | 0.24 in | Board to Cable/Wire | UL94 V-0 | Through Hole | All | 105 ░C | -25 °C | 250 VAC |
