67025 Series

Catalog

HOOK-UP STRND 24AWG G/Y 1640.4'

Part	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Conductor Strand [diameter]	Conductor Strand [custom]	Length [x]	Length [x]	Jacket (Insulation) Material	Cable Type	Ratings	Voltage	Operating Temperature [Min]	Operating Temperature [Max]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Jacket Color	Length	Length
ALPHA WIRE 67025 GY034	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32	1640.4 ft	500 m	Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	Green Yellow Stripe
ALPHA WIRE 67025 YL321	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32			Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	Yellow	50 m	164 ft
ALPHA WIRE 67025 BL033	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32	328.1 ft	100 m	Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	Blue
ALPHA WIRE 67025 WH321	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32			Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	White	50 m	164 ft
ALPHA WIRE 67025 BL034	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32	1640.4 ft	500 m	Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	Blue
ALPHA WIRE 67025 RD033	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32	328.1 ft	100 m	Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	Red
ALPHA WIRE 67025 YL034	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32	1640.4 ft	500 m	Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	Yellow
ALPHA WIRE 67025 BR033	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32	328.1 ft	100 m	Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	Brown
ALPHA WIRE 67025 OR321	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32			Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	Orange	50 m	164 ft
ALPHA WIRE 67025 WH033	0.25 mm	0.01 in	Copper Tinned	0.0039 "	32	328.1 ft	100 m	Polyphenylene Ether Modified (mPPE)	Hook-Up	UL Style 11028	600 V	-40 C	105 ░C	0.045 in	1.14 mm	24 AWG	White
