EMX-7T05 Series
Manufacturer: East Electronics
Beta
⌘K
BUZZER 5V 12MM TH
| Part | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Voltage - Rated | Sound Pressure Level (SPL) | Termination | Mounting Type | Current - Supply | Frequency | Size / Dimension [diameter] | Size / Dimension [diameter] | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Range [Max] | Voltage Range [Min] | Operating Mode |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 East Electronics | 10 mm | 0.394 in | 5 V | 85 dB | PC Pins | Through Hole | 30 mA | 2.3 kHz | 0.472 " | 12 mm | 85 °C | -40 C | 6.5 V | 4 VDC | Continuous |
