1634689 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER R/A 20POS 2.54MM

Part	Material Flammability Rating	Number of Positions Loaded	Contact Length - Mating	Contact Length - Mating	Style	Number of Rows [custom]	Contact Finish - Mating	Contact Shape	Pitch - Mating	Pitch - Mating	Termination	Insulation Material	Current Rating (Amps)	Fastening Type	Number of Positions	Mounting Type	Features	Contact Length - Post [x]	Contact Length - Post [x]	Shrouding	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Type	Insulation Height	Insulation Height	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Contact Finish - Post	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Insulation Color
TE Connectivity AMP Connectors 2-1634689-0	UL94 V-0	All	0.228 in	5.8 mm	Board to Cable/Wire	2	Gold	Square	0.1 "	2.54 mm	Solder	Nylon 6T Polyamide (PA6T)	3 A	Push-Pull	20	Right Angle Through Hole	Keying Slot	0.126 "	3.2 mm	Shrouded - 4 Wall	2.03 µm	80 µin	0.1 in	2.54 mm	Male Pin	0.335 "	8.51 mm	0.25 µm	10 µin	Brass	Tin	-40 C	105 ░C	Header	Black
TE Connectivity AMP Connectors 1-1634689-4	UL94 V-0	All	0.228 in	5.8 mm	Board to Cable/Wire	2	Gold	Square	0.1 "	2.54 mm	Solder	Nylon 6T Polyamide (PA6T)	3 A	Push-Pull	14	Right Angle Through Hole	Keying Slot	0.126 "	3.2 mm	Shrouded - 4 Wall	2.03 µm	80 µin	0.1 in	2.54 mm	Male Pin	0.335 "	8.51 mm	0.25 µm	10 µin	Brass	Tin	-40 C	105 ░C	Header	Black
TE Connectivity AMP Connectors 2-1634689-6	UL94 V-0	All	0.228 in	5.8 mm	Board to Cable/Wire	2	Gold	Square	0.1 "	2.54 mm	Solder	Nylon 6T Polyamide (PA6T)	3 A	Push-Pull	26	Right Angle Through Hole	Keying Slot	0.126 "	3.2 mm	Shrouded - 4 Wall	2.03 µm	80 µin	0.1 in	2.54 mm	Male Pin	0.335 "	8.51 mm	0.25 µm	10 µin	Brass	Tin	-40 C	105 ░C	Header	Black
TE Connectivity AMP Connectors 1-1634689-6	UL94 V-0	All	0.228 in	5.8 mm	Board to Cable/Wire	2	Gold	Square	0.1 "	2.54 mm	Solder	Nylon 6T Polyamide (PA6T)	3 A	Push-Pull	16	Right Angle Through Hole	Keying Slot	0.126 "	3.2 mm	Shrouded - 4 Wall	2.03 µm	80 µin	0.1 in	2.54 mm	Male Pin	0.335 "	8.51 mm	0.25 µm	10 µin	Brass	Tin	-40 C	105 ░C	Header	Black
