392-051 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows | Material - Insulation | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Read Out | Number of Positions/Bay/Row [custom] | Color | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Gender | Mounting Type | Contact Finish | Number of Positions | Card Type | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder Wire Wrap | Single | 51 | Black | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Right Angle Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy |
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder Wire Wrap | Single | 51 | Black | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Right Angle Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder | Single | 51 | Black | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy |
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder Wire Wrap | Single | 51 | Black | Flush Mount M3 Threaded Insert Top Opening | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Right Angle Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Wire Wrap | Single | 51 | Black | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy |
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Wire Wrap | Single | 51 | Black | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy |
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Wire Wrap | Single | 51 | Black | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy |
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Wire Wrap | Single | 51 | Black | Flush Mount M3 Threaded Insert Top Opening | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder | Single | 51 | Black | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy |
 EDAC Inc. | 1 | Polyester Thermoplastic | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Solder | Single | 51 | Black | 4-40 Flush Mount Threaded Insert Top Opening | 1 | 0.25 Ám | 10 Áin | 0.1 " | 2.54 mm | Female | Through Hole | Gold | 51 | Non Specified - Single Edge | Copper Alloy |
