306-018 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 36POS 0.156
| Part | Material - Insulation | Termination Rows | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Color | Gender | Number of Rows [custom] | Contact Type | Read Out | Flange Feature | Number of Positions/Bay/Row [custom] | Contact Finish | Features | Card Type | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Pitch | Pitch | Termination | Number of Positions | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Panel Mount | Green | Female | 2 | Cantilever | Dual | 4-40 Flush Mount Threaded Insert Top Opening | 18 | Tin | Card Guides | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder Eyelet(s) | 36 | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Panel Mount | Green | Female | 2 | Cantilever | Dual | Flush Mount Top Opening Unthreaded | 18 | Gold | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder Eyelet(s) | 36 | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Through Hole | Green | Female | 2 | Cantilever | Dual | 18 | Tin | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder | 36 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Panel Mount Through Hole | Green | Female | 2 | Cantilever | Dual | Floating Bobbin Flush Mount | 18 | Gold | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder | 36 | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Panel Mount Through Hole | Green | Female | 2 | Cantilever | Dual | Flush Mount Top Opening Unthreaded | 18 | Tin | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder | 36 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Panel Mount | Green | Female | 2 | Cantilever | Dual | Flush Mount Top Opening Unthreaded | 18 | Gold | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder Eyelet(s) | 36 | 0.128 " | 3.25 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Through Hole | Green | Female | 2 | Cantilever | Dual | Flush Mount Top Opening Unthreaded | 18 | Gold | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder | 36 | 0.156 " | 3.96 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Through Hole | Green | Female | 2 | Cantilever | Dual | 18 | Gold | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder | 36 | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Panel Mount | Green | Female | 2 | Cantilever | Dual | Flush Mount M3 Threaded Insert Top Opening | 18 | Gold | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder Eyelet(s) | 36 | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | -40 C | 105 ░C | Panel Mount | Green | Female | 2 | Cantilever | Dual | 4-40 Flush Mount Threaded Insert Top Opening | 18 | Gold | Card Guides | Non Specified - Dual Edge | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 3.96 mm | 0.156 in | Solder Eyelet(s) | 36 | 0.25 Ám | 10 Áin |
