16SVPS Series

Catalog

CAP ALUM POLY 82UF 20% 16V SMD

Part	Operating Temperature [Min]	Operating Temperature [Max]	Capacitance	Tolerance	Type	ESR (Equivalent Series Resistance)	Package / Case	Lifetime @ Temp.	Ripple Current @ Low Frequency	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Surface Mount Land Size [x]	Surface Mount Land Size [y]	Surface Mount Land Size [x]	Surface Mount Land Size [y]	Size / Dimension [diameter]	Size / Dimension [diameter]	Mounting Type	Applications	Ripple Current @ High Frequency	Voltage - Rated	Height - Seated (Max)
Panasonic Electronic Components 16SVPS82M	-55 C	105 ░C	0.082 mF	20 %	Polymer	30 mOhms	Radial Can - SMD	5000 Hrs	138 mA	0.276 in	7 mm	8.3 mm	8.3 mm	0.327 in	0.327 in	0.315 in	8 mm	Surface Mount	General Purpose	2.76 A	16 V
Panasonic Electronic Components 16SVPS39M	-55 C	105 ░C	39 µF	20 %	Polymer	24 mOhms	Radial Can - SMD	5000 Hrs	123 mA	0.236 "		6.6 mm	6.6 mm	0.26 in	0.26 in	0.248 "	6.3 mm	Surface Mount	General Purpose	2.46 A	16 V	6 mm
Panasonic Electronic Components 16SVPS100M	-55 C	105 ░C	100 µF	20 %	Polymer	35 mOhms	Radial Can - SMD	5000 Hrs	133.5 mA	0.315 in	8 mm	10.3 mm	10.3 mm	0.406 "	0.406 in	0.394 in	10 mm	Surface Mount	General Purpose	2.67 A	16 V
