937-SP-36 Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
MODULAR CONNECTORS / ETHERNET CONNECTORS MODULAR PLUG STANDARD 6P 6C SHIELDED .032-.038 CONDUCTORS
| Part | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Housing Material | Voltage Rating | Shield Material | Current Rating (Amps) | Contact Finish | Color | Termination | Features | Connector Type | Number of Positions/Contacts [y] | Number of Positions/Contacts [x] | Shielding | Cable Type | Length | Length | Number of Positions/Contacts [custom] | Number of Positions/Contacts [custom] | Number of Positions/Contacts |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | Phosphor Bronze | 50 µin | 1.27 µm | Polycarbonate (PC) | 150 VDC | Brass | 1.5 A | Gold | Translucent - Clear | IDC | Molded Boot | Plug | 6 | 6 | Shielded | Flat Oval Cable Stranded Wires | 26.57 mm | 1.046 in | |||
 Bel Fuse Inc. | Phosphor Bronze | 50 µin | 1.27 µm | Polycarbonate (PC) | 150 VDC | Brass | 1.5 A | Gold | Translucent - Clear | IDC | Keyed Molded Boot | Plug | Shielded | Flat Oval Cable Stranded Wires | 26.57 mm | 1.046 in | 10 | 10 | |||
 Bel Fuse Inc. | Phosphor Bronze | 50 µin | 1.27 µm | Polycarbonate (PC) | 150 VDC | Brass | 1.5 A | Gold | Black Boot Translucent - Clear | IDC | Molded Boot | Plug | Shielded | Flat Oval Cable Stranded Wires | 26.57 mm | 1.046 in | 8p8c (RJ45 Ethernet) | ||||
 Bel Fuse Inc. | Phosphor Bronze | 50 µin | 1.27 µm | Polycarbonate (PC) | 150 VDC | Brass | 1.5 A | Gold | Translucent - Clear | IDC | Molded Boot | Plug | Shielded | Flat Oval Cable Stranded Wires | 26.57 mm | 1.046 in | 8p8c (RJ45 Ethernet) | ||||
 Bel Fuse Inc. | Phosphor Bronze | 50 µin | 1.27 µm | Polycarbonate (PC) | 150 VDC | Brass | 1.5 A | Gold | Translucent - Clear | IDC | Plug | Shielded | Flat Oval Cable Stranded Wires | 26.57 mm | 1.046 in | 10 | 10 |
