W3AF1C-P Series
Manufacturer: ODU
Beta
⌘K
ODU MINI-SNAP RT.ANGLE PLUG, STY
| Part | Shell Finish | Material Flammability Rating | Connector Type | Backshell Material, Plating | Applications | Current Rating (Amps) | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Orientation [custom] | Color | Shell Material | Ingress Protection | Primary Material | Cable Opening [Min] | Cable Opening [Max] | Cable Opening [Max] | Cable Opening [Min] | Shielding | Mounting Type | Shell Size - Insert [custom] | Voltage Rating | Insert Material | Features | Number of Positions | Fastening Type | Contact Finish - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Chrome over Nickel | UL94 V-0 | Plug Male Pins | Brass Chrome over Nickel | Industrial Medical Military Testing Equipment & Measurement | 7.5 A | 120 °C | -40 C | Brass | 1 | Silver | Brass | IP68 - Dust Tight Waterproof | Metal | 0.276 " | 0.295 in | 7.5 mm | 7 mm | Unshielded | Free Hanging (In-Line) Right Angle | 1.5 | 300 VDC | Polyetheretherketone (PEEK) | Backshell | 12 | Push-Pull | Gold |
