310-87 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 37P 0.1 GOLD SMD R/A
| Part | Insulation Material | Contact Shape | Contact Material | Contact Finish - Mating | Number of Rows | Fastening Type | Insulation Color | Contact Finish Thickness - Mating | Contact Type | Contact Finish - Post | Material Flammability Rating | Number of Positions | Insulation Height | Insulation Height | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Connector Type | Mounting Type | Number of Positions Loaded | Pitch - Mating | Pitch - Mating | Contact Length - Post [x] | Contact Length - Post [x] | Features | Contact Length - Post | Contact Length - Post |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 37 | 0.1 in | 2.54 mm | Solder | -55 C | 125 °C | 3 A | Socket | Right Angle Surface Mount | All | 0.1 " | 2.54 mm | |||||
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 2 | 0.1 in | 2.54 mm | Solder | -55 C | 125 °C | 3 A | Socket | Right Angle Surface Mount | All | 0.1 " | 2.54 mm | |||||
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 54 | 0.165 in | 4.2 mm | Press-Fit Solder | -55 C | 125 °C | 3 A | Socket | Through Hole | All | 0.1 " | 2.54 mm | 0.122 in | 3.1 mm | |||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 61 | 0.165 in | 4.2 mm | Press-Fit Solder | -55 C | 125 °C | 3 A | Socket | Through Hole | All | 0.1 " | 2.54 mm | 0.122 in | 3.1 mm | |||
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 8 | 0.165 in | 4.2 mm | Press-Fit Solder | -55 C | 125 °C | 3 A | Socket | Through Hole | All | 0.1 " | 2.54 mm | 0.122 in | 3.1 mm | |||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 25 | 0.165 in | 4.2 mm | Press-Fit Solder | -55 C | 125 °C | 3 A | Socket | Through Hole | All | 0.1 " | 2.54 mm | 0.122 in | 3.1 mm | |||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 7 | 0.165 in | 4.2 mm | Press-Fit Solder | -55 C | 125 °C | 3 A | Socket | Through Hole | All | 0.1 " | 2.54 mm | 0.122 in | 3.1 mm | |||
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 0.22 in | 5.6 mm | Solder | -55 C | 125 °C | 3 A | Socket | Surface Mount | All | 0.1 " | 2.54 mm | Pick and Place | |||||
 Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 5 | 0.165 in | 4.2 mm | Solder | -55 C | 125 °C | 3 A | Socket | Through Hole | All | 0.1 " | 2.54 mm | 0.125 in | 3.18 mm | |||
Preci-Dip | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Beryllium Copper | Gold | 1 | Push-Pull | Black | Flash | Female Socket | Tin | UL94 V-0 | 10 | 0.1 in | 2.54 mm | Solder | -55 C | 125 °C | 3 A | Socket | Right Angle Surface Mount | All | 0.1 " | 2.54 mm |
