GHA500F Series

Catalog

AC/DC POWER SUPPLY SINGLE-OUT 12V 41.7A 500.8W MEDICAL 11-PIN

Part	Operating Temperature [Max]	Operating Temperature [Min]	Efficiency	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Applications	Approval Agency	Voltage - Input [Max]	Voltage - Input [Min]	Current - Output 1	Type	Features	Power (Watts)	Power (Watts)	Voltage - Isolation	Mounting Type	Number of Outputs	Voltage - Output 1
Cosel USA, Inc. GHA500F-12-R3	80 ¯C	-20 °C	89 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	12.5 A	Open Frame	Adjustable Output DC Input Capable PFC Remote On/Off Standby Output Universal Input	150 W	500 W	4000 V	Chassis Mount	1	12 V
Cosel USA, Inc. GHA500F-48-T3	80 ¯C	-20 °C	91 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	3.2 A	Open Frame	Adjustable Output DC Input Capable Universal Input	150 W	500 W	4000 V	Chassis Mount	1	48 V
Cosel USA, Inc. GHA500F-24-P	80 ¯C	-20 °C	91 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	6.3 A	Open Frame	Adjustable Output DC Input Capable Load Sharing PFC Universal Input	150 W	500 W	4000 V	Chassis Mount	1	24 V
Cosel USA, Inc. GHA500F-48-SNF	80 ¯C	-20 °C	91 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	10.5 A	Enclosed	Adjustable Output DC Input Capable PFC Universal Input	504 W		4000 V	Chassis Mount	1	48 V
Cosel USA, Inc. GHA500F-12-SNF	80 ¯C	-20 °C	89 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	37.5 A	Enclosed	Adjustable Output DC Input Capable PFC Universal Input	450 W		4000 V	Chassis Mount	1	12 V
Cosel USA, Inc. GHA500F-24-J1	80 ¯C	-20 °C	91 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	6.3 A	Open Frame	Adjustable Output DC Input Capable Universal Input	150 W	500 W	4000 V	Chassis Mount	1	24 V
Cosel USA, Inc. GHA500F-15	80 ¯C	-20 °C	91 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	10 A	Open Frame	Adjustable Output DC Input Capable Universal Input	150 W	500 W	4000 V	Chassis Mount	1	15 V
Cosel USA, Inc. GHA500F-48-P	80 ¯C	-20 °C	91 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	3.2 A	Open Frame	Adjustable Output DC Input Capable Load Sharing PFC Universal Input	150 W	500 W	4000 V	Chassis Mount	1	48 V
Cosel USA, Inc. GHA500F-15-SNF	80 ¯C	-20 °C	91 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	33.4 A	Enclosed	Adjustable Output DC Input Capable PFC Universal Input	501 W		4000 V	Chassis Mount	1	15 V
Cosel USA, Inc. GHA500F-24-R3	80 ¯C	-20 °C	91 %	35 mm	127 mm	5 "	3 "	1.38 in	76.2 mm	ITE (Commercial) Medical	CE cURus DEMKO	264 VAC	90 VAC	6.3 A	Open Frame	Adjustable Output DC Input Capable PFC Remote On/Off Standby Output Universal Input	150 W	500 W	4000 V	Chassis Mount	1	24 V
