10090928 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN D-SUB HD PLUG 78P VERT SLDR
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Contact Material | Voltage Rating | Contact Finish | Shell Material, Finish | Material Flammability Rating | Termination | Contact Type | Connector Type | Mounting Type | Current Rating (Amps) | Flange Feature | Connector Style | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Features | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout | Number of Rows [custom] | Shell Size, Connector Layout [custom] | Contact Finish Thickness | Shell Size, Connector Layout |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 105 ░C | Black | Copper Alloy | 250 V | Gold | Nickel Plated Steel | UL94 V-0 | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) | D-Sub High Density | 30 Áin | 0.76 Ám | 78 | Board Lock Grounding Indents | ||||||
 Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 105 ░C | Black | Copper Alloy | 250 V | Gold | Nickel Plated Steel | UL94 V-0 | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) Mating Side Female Screwlock (4-40) | D-Sub High Density | 30 Áin | 0.76 Ám | 26 | Board Lock Grounding Indents | 2 | DA A | 3 | |||
Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 105 ░C | Black | Copper Alloy | 250 V | Gold | Nickel Plated Steel | UL94 V-0 | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) Mating Side Female Screwlock (4-40) | D-Sub High Density | 30 Áin | 0.76 Ám | 78 | Board Lock Grounding Indents | ||||||
Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 125 °C | Black | Brass | 250 V | Gold | Nickel Plated Steel | UL94 V-0 | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) Mating Side Female Screwlock (4-40) | D-Sub High Density | 30 Áin | 0.76 Ám | 15 | Board Lock Grounding Indents | 1 | 3 | (DE E) High Density | |||
 Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 105 ░C | Black | Copper Alloy | 250 V | Gold | Nickel Plated Steel | UL94 V-0 | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) Mating Side Female Screwlock (4-40) | D-Sub High Density | 30 Áin | 0.76 Ám | 15 | Board Lock Grounding Indents | 1 | 3 | (DE E) High Density | |||
Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 105 ░C | Black | Copper Alloy | 250 V | Gold | Nickel Plated Steel | UL94 V-0 | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) | D-Sub High Density | 30 Áin | 0.76 Ám | 26 | Board Lock Grounding Indents | 2 | DA A | 3 | |||
 Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 105 ░C | Black | Copper Alloy | 250 V | Gold | Nickel Plated Steel | UL94 V-0 | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) | D-Sub High Density | 26 | Board Lock Grounding Indents | 2 | DA A | 3 | Flash | ||||
 Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 105 ░C | Black | Copper Alloy | 250 V | Gold | Nickel Plated Steel | UL94 V-0 | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) | D-Sub High Density | 44 | Board Lock Grounding Indents | 3 | Flash | 3 | |||||
 Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 105 ░C | Black | Copper Alloy | 250 V | Gold | Nickel Plated Steel | UL94 V-0 | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) Mating Side Female Screwlock (4-40) | D-Sub High Density | 15 | Board Lock Grounding Indents | 1 | 3 | (DE E) High Density | Flash | ||||
 Amphenol ICC (FCI) | Thermoplastic Glass Filled | -55 C | 105 ░C | Black | Copper Alloy | 250 V | Gold | Nickel Plated Steel | Solder | Signal | Plug Male Pins | Through Hole | 2.5 A | Board Side (4-40) Mating Side Female Screwlock (4-40) | D-Sub High Density | 26 | Board Lock Grounding Indents | 2 | DA A | 3 | Flash |
