92008 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN HEADER VERT 3POS 2.5MM
| Part | Connector Type | Contact Finish - Post | Shrouding | Contact Type | Style | Number of Rows | Insulation Color | Pitch - Mating | Pitch - Mating | Number of Positions Loaded | Contact Length - Post | Contact Length - Post | Fastening Type | Termination | Contact Material | Insulation Material | Mounting Type | Contact Shape | Insulation Height | Insulation Height | Material Flammability Rating | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Header | Tin | Unshrouded | Male Pin | Board to Cable/Wire | 1 | White | 2.5 mm | 0.098 in | All | 0.13 " | 3.3 mm | Locking Ramp | Kinked Pin Solder | Brass | Nylon Polyamide (PA) | Through Hole | Circular | 6.48 mm | 0.255 in | UL94 V-0 | |
 TE Connectivity AMP Connectors | Header | Tin | Unshrouded | Male Pin | Board to Cable/Wire | 1 | White | 2.5 mm | 0.098 in | All | 0.13 " | 3.3 mm | Locking Ramp | Kinked Pin Solder | Brass | Nylon Polyamide (PA) | Through Hole | Circular | 6.48 mm | 0.255 in | UL94 V-0 | 2 |
TE Connectivity AMP Connectors | Header | Tin | Unshrouded | Male Pin | Board to Cable/Wire | 1 | White | 2.5 mm | 0.098 in | All | 0.13 " | 3.3 mm | Locking Ramp | Kinked Pin Solder | Brass | Nylon Polyamide (PA) | Through Hole | Circular | 6.48 mm | 0.255 in | UL94 V-0 | 4 |
