CDFS3W3 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB RCPT 3POS PNL MNT
| Part | Color | Contact Material | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Flange Feature | Connector Type | Connector Style | Contact Finish Thickness | Shell Material, Finish | Material Flammability Rating | Ingress Protection | Number of Rows | Current Rating (Amps) | Contact Type | Contact Finish | Shell Size, Connector Layout | Mounting Type | Current Rating (Amps) | Features | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Black | Brass | Polybutylene Terephthalate (PBT) | 85 °C | -25 °C | 3 | 4-40 Mating Side Female Screwlock | Receptacle Female Sockets | Combo D-Sub | Flash | Nickel Plated Steel | UL94 V-0 | IP67 - Dust Tight Waterproof | 1 | 40 A | Power | Gold | 2 (DA A) - 3W3 | Panel Mount | ||||
 NorComp Inc. | Black | Brass | Polybutylene Terephthalate (PBT) | 85 °C | -25 °C | 3 | 4-40 Mating Side Female Screwlock | Plug Male Pins | Combo D-Sub | Nickel Plated Steel | UL94 V-0 | IP67 - Dust Tight Waterproof | 1 | Power | Gold | 2 (DA A) - 3W3 | Panel Mount | 20A 5A | Grounding Indents | 30 Áin | 0.76 Ám | ||
 NorComp Inc. | Black | Brass | Polybutylene Terephthalate (PBT) | 85 °C | -25 °C | 3 | 4-40 Mating Side Female Screwlock | Receptacle Female Sockets | Combo D-Sub | Flash | Nickel Plated Steel | UL94 V-0 | IP67 - Dust Tight Waterproof | 1 | 20 A | Power | Gold | 2 (DA A) - 3W3 | Panel Mount | ||||
 NorComp Inc. | Black | Brass | Polybutylene Terephthalate (PBT) | 85 °C | -25 °C | 3 | 4-40 Mating Side Female Screwlock | Plug Male Pins | Combo D-Sub | Flash | Nickel Plated Steel | UL94 V-0 | IP67 - Dust Tight Waterproof | 1 | 20 A | Power | Gold | 2 (DA A) - 3W3 | Panel Mount | Grounding Indents | |||
 NorComp Inc. | Black | Brass | Polybutylene Terephthalate (PBT) | 85 °C | -25 °C | 3 | 4-40 Mating Side Female Screwlock | Plug Male Pins | Combo D-Sub | Nickel Plated Steel | UL94 V-0 | IP67 - Dust Tight Waterproof | 1 | 20 A | Power | Gold | 2 (DA A) - 3W3 | Panel Mount | Grounding Indents | 30 Áin | 0.76 Ám | ||
 NorComp Inc. | Black | Brass | Polybutylene Terephthalate (PBT) | 85 °C | -25 °C | 3 | 4-40 Mating Side Female Screwlock | Receptacle Female Sockets | Combo D-Sub | Nickel Plated Steel | UL94 V-0 | IP67 - Dust Tight Waterproof | 1 | Power | Gold | 2 (DA A) - 3W3 | Panel Mount | 20A 5A | 30 Áin | 0.76 Ám | |||
NorComp Inc. | Black | Brass | Polybutylene Terephthalate (PBT) | 85 °C | -25 °C | 3 | 4-40 Mating Side Female Screwlock | Plug Male Pins | Combo D-Sub | Flash | Nickel Plated Steel | UL94 V-0 | IP67 - Dust Tight Waterproof | 1 | 40 A | Power | Gold | 2 (DA A) - 3W3 | Panel Mount | Grounding Indents | |||
 NorComp Inc. | Black | Brass | Polybutylene Terephthalate (PBT) | 85 °C | -25 °C | 3 | 4-40 Mating Side Female Screwlock | Receptacle Female Sockets | Combo D-Sub | Nickel Plated Steel | UL94 V-0 | IP67 - Dust Tight Waterproof | 1 | 20 A | Power | Gold | 2 (DA A) - 3W3 | Panel Mount | 30 Áin | 0.76 Ám |
