SRP7030 Series
Manufacturer: Bourns Inc.
Beta
⌘K
IND7X7.8X3.2MM,3.3UH20%6A,SHDSMD /TAPE & REEL - 13" REEL ROHS COMPLIANT: YES
| Part | Tolerance | DC Resistance (DCR) [Max] | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Current - Saturation (Isat) | Mounting Type | Current Rating (Amps) | Material - Core | Shielding | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Inductance Frequency - Test | Package / Case | Inductance | DC Resistance (DCR) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | 20 % | 30 mOhm | 0.126 in | 3.2 mm | 10 A | Surface Mount | 6 A | Iron | Shielded | 125 °C | -40 C | 7.8 mm | 7 mm | 0.307 " | 0.276 in | 100 kHz | Nonstandard | 3.3 µH | |
 Bourns Inc. | 20 % | 85 mOhm | 0.126 in | 3.2 mm | 4.5 A | Surface Mount | 3 A | Iron | Shielded | 125 °C | -40 C | 7.8 mm | 7 mm | 0.307 " | 0.276 in | 100 kHz | Nonstandard | 10 µH | |
Bourns Inc. | 20 % | 68 mOhm | 0.126 in | 3.2 mm | 5.5 A | Surface Mount | 4 A | Iron | Shielded | 125 °C | -40 C | 7.8 mm | 7 mm | 0.307 " | 0.276 in | 100 kHz | Nonstandard | 8.2 µH | |
 Bourns Inc. | 20 % | 10 mOhm | 0.126 in | 3.2 mm | 15 A | Surface Mount | 11 A | Iron | Shielded | 125 °C | -40 C | 7.8 mm | 7 mm | 0.307 " | 0.276 in | 100 kHz | Nonstandard | 1 µH | |
 Bourns Inc. | 20 % | 0.126 in | 3.2 mm | 42 A | Surface Mount | 32.5 A | Iron | Shielded | 125 °C | -40 C | 7.8 mm | 7 mm | 0.307 " | 0.276 in | 100 kHz | Nonstandard | 100 nH | 1.7 mOhm | |
Bourns Inc. | 20 % | 5.5 mOhm | 0.126 in | 3.2 mm | 23 A | Surface Mount | 15.5 A | Iron | Shielded | 125 °C | -40 C | 7.8 mm | 7 mm | 0.307 " | 0.276 in | 100 kHz | Nonstandard | 0.68 µH | |
Bourns Inc. | 20 % | 3.9 mOhm | 0.126 in | 3.2 mm | 30 A | Surface Mount | 20 A | Iron | Shielded | 125 °C | -40 C | 7.8 mm | 7 mm | 0.307 " | 0.276 in | 100 kHz | Nonstandard | 330 nH | |
Bourns Inc. | 20 % | 15 mOhm | 0.126 in | 3.2 mm | 14 A | Surface Mount | 9 A | Iron | Shielded | 125 °C | -40 C | 7.8 mm | 7 mm | 0.307 " | 0.276 in | 100 kHz | Nonstandard | 1.5 µH |
