OQ083 Series

Catalog

OQ - 3.81- 8P BLACK, LCP THR , P

Part	Pitch [x]	Pitch [x]	Current - UL	Insulation Height	Insulation Height	Contact Tail Length	Contact Tail Length	Color	Header Orientation	Operating Temperature [Min]	Operating Temperature [Max]	Termination Style	Number of Positions	Positions Per Level	Mounting Type	Material Flammability Rating	Number of Levels	Housing Material	Type	Voltage - UL	Contact Mating Finish	Contact Material	Insulation Height [z]	Insulation Height [z]
Amphenol Anytek OQ083G00B000G	0.15 in	3.81 mm	10 A	0.362 in	9.2 mm	0.102 in	2.6 mm	Black	Vertical	-45 °C	130 °C	Solder	8	8	Through Hole	UL94 V-0	1	Liquid Crystal Polymer (LCP)	Header Male Pins Shrouded (4 Side)	300 V	Tin	Copper
Amphenol Anytek OQ083G01B000G	0.15 in	3.81 mm	10 A			0.102 in	2.6 mm	Black	90° Right Angle	-45 °C	130 °C	Solder	8	8	Through Hole	UL94 V-0	1	Liquid Crystal Polymer (LCP)	Header Male Pins Shrouded (4 Side)	300 V	Tin	Copper	7 mm	0.276 in
