TP-BC72 Series
Manufacturer: Tycon Systems Inc.
Beta
⌘K
BATT CHARGER DESKTOP 88.2V 6A
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Approval Agency | Type | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Mounting Type | Battery Cell Size | Number of Cells | Charge Current - Max [Max] | Termination Style | Features | Voltage - Nominal | Voltage - Input [Min] | Voltage - Input [Max] | Power - Max [Max] | Battery Chemistry | Size / Dimension [z] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Tycon Systems Inc. | 40 °C | -10 °C | CE | Desktop | 76.2 mm | 8.5 " | 4.75 " | 3 in | 120.65 mm | 215.9 mm | Desktop | 72 V | 1 | 6 A | Wire Leads | LED Indicator | 88.2 V | 90 VAC | 240 VAC | 600 W | Lead Acid | ||
 Tycon Systems Inc. | 40 °C | -10 °C | CE | Desktop | 10.7 in | 5.3 " | 2.75 in | 271.78 mm | Desktop | 72 V | 1 | 10 A | Wire Leads | LED Indicator | 88.2 V | 90 VAC | 240 VAC | 900 W | Lead Acid | 69.85 mm | 134.62 mm |
