Isolated DC/DC Converters - Through Hole
Isolated DC/DC Converters - Through Hole
| Part | Features | Approval Agency | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Type | Efficiency | Voltage - Output 1 | Power (Watts) | Standard Number | Applications | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Control Features | Package / Case | Voltage - Input (Max) [Max] | Voltage - Isolation | Voltage - Output 2 | Number of Outputs | Voltage - Input (Min) [Min] | Current - Output (Max) | Current - Output (Max) [Max] | Current - Output (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Through Hole | -40 °C | 85 °C | Isolated Module | 84 % | 5 V | 10 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 10.2 mm | 0.4 " | 25.4 mm | Active High Enable | 6-DIP Module | 75 V | 1.5 kV | -5 V | 2 | 18 V | 1 A | ||
 Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Surface Mount | -40 °C | 85 °C | Isolated Module | 87 % | 12 V | 10 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 9.2 mm | 0.36 in | 25.4 mm | 6-SMD Module | 18 V | 1.5 kV | -12 V | 2 | 9 V | 416 mA | 416 mA | ||
Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Through Hole | -40 °C | 85 °C | Isolated Module | 81 % | 3.3 V | 8.3 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 10.2 mm | 0.4 " | 25.4 mm | Active Low Enable | 6-DIP Module | 36 V | 1.5 kV | 1 | 9 V | 2.5 A | |||
Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Surface Mount | -40 °C | 85 °C | Isolated Module | 87 % | 15 V | 10 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 9.2 mm | 0.36 in | 25.4 mm | 6-SMD Module | 9 V | 1.5 kV | 1 | 4.7 V | 666 mA | ||||
Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Surface Mount | -40 °C | 85 °C | Isolated Module | 87 % | 12 V | 10 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 9.2 mm | 0.36 in | 25.4 mm | 6-SMD Module | 18 V | 1.5 kV | 1 | 9 V | 833 mA | ||||
Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Through Hole | -40 °C | 85 °C | Isolated Module | 3.3 V | 8.3 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 10.2 mm | 0.4 " | 25.4 mm | 6-DIP Module | 36 V | 1.5 kV | 1 | 18 V | 2.5 A | |||||
 Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Through Hole | -40 °C | 85 °C | Isolated Module | 86 % | 15 V | 10 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 10.2 mm | 0.4 " | 25.4 mm | Active Low Enable | 6-DIP Module | 36 V | 1.5 kV | 1 | 9 V | 666 mA | |||
Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Through Hole | -40 °C | 85 °C | Isolated Module | 85 % | 5 V | 10 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 10.2 mm | 0.4 " | 25.4 mm | 6-DIP Module | 9 V | 1.5 kV | -5 V | 2 | 4.7 V | 1 A | |||
Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Surface Mount | -40 °C | 85 °C | Isolated Module | 3.3 V | 8.3 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 9.2 mm | 0.36 in | 25.4 mm | 6-SMD Module | 36 V | 1.5 kV | 1 | 18 V | 2.5 A | |||||
Cincon Electronics Co. LTD | OCP OVP Remote On/Off SCP UVLO | CE | Through Hole | -40 °C | 85 °C | Isolated Module | 87 % | 12 V | 10 W | 60950-1 | ITE (Commercial) | 1 " | 1 in | 25.4 mm | 10.2 mm | 0.4 " | 25.4 mm | 6-DIP Module | 75 V | 1.5 kV | 1 | 36 V | 833 mA |
