HPC 4012BMV Series

Manufacturer: TAI-TECH Advanced Electronics Co., Ltd.

Catalog

FIXED IND 33UH 700MA 1.02OHM SMD

Part	Material - Core	Package / Case	Mounting Type	Type	Inductance Frequency - Test	Shielding	DC Resistance (DCR)	Tolerance	Current - Saturation (Isat)	Current Rating (Amps)	Inductance	Ratings	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	DC Resistance (DCR) [Max]
TAI-TECH Advanced Electronics Co., Ltd. HPC 4012BMV-330M	Ferrite	1616 (4040 Metric)	Surface Mount	Wirewound	100 kHz	Shielded	1.02 Ohm	20 %	550 mA	700 mA	33 µH	AEC-Q200	1.2 mm	0.047 "	-55 C	125 °C	4012	0.157 "	4 mm	0.157 in	4 mm
TAI-TECH Advanced Electronics Co., Ltd. HPC 4012BMV-1R0M	Ferrite	1616 (4040 Metric)	Surface Mount	Wirewound	100 kHz	Shielded		20 %	3.6 A	4.2 A	1 µH	AEC-Q200	1.2 mm	0.047 "	-55 C	125 °C	4012	0.157 "	4 mm	0.157 in	4 mm
TAI-TECH Advanced Electronics Co., Ltd. HPC 4012BMV-4R7M	Ferrite	1616 (4040 Metric)	Surface Mount	Wirewound	100 kHz	Shielded		20 %	1.4 A	2.3 A	4.7 ÁH	AEC-Q200	1.2 mm	0.047 "	-55 C	125 °C	4012	0.157 "	4 mm	0.157 in	4 mm	134 mOhm
TAI-TECH Advanced Electronics Co., Ltd. HPC 4012BMV-220M	Ferrite	1616 (4040 Metric)	Surface Mount	Wirewound	100 kHz	Shielded		20 %	0.6 A	900 mA	22 µH	AEC-Q200	1.2 mm	0.047 "	-55 C	125 °C	4012	0.157 "	4 mm	0.157 in	4 mm	564 mOhm
TAI-TECH Advanced Electronics Co., Ltd. HPC 4012BMV-100M	Ferrite	1616 (4040 Metric)	Surface Mount	Wirewound	100 kHz	Shielded		20 %	900 mA	1.2 A	10 µH	AEC-Q200	1.2 mm	0.047 "	-55 C	125 °C	4012	0.157 "	4 mm	0.157 in	4 mm	276 mOhm
TAI-TECH Advanced Electronics Co., Ltd. HPC 4012BMV-2R2M	Ferrite	1616 (4040 Metric)	Surface Mount	Wirewound	100 kHz	Shielded		20 %	2.3 A	3 A	2.2 µH	AEC-Q200	1.2 mm	0.047 "	-55 C	125 °C	4012	0.157 "	4 mm	0.157 in	4 mm	79.2 mOhm
