396-009 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 9POS 0.125
| Part | Termination Rows | Material - Insulation | Termination | Number of Rows | Contact Finish | Flange Feature | Contact Type | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Number of Positions/Bay/Row | Contact Material | Card Type | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Color | Read Out | Features | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 1 | Gold | M3 Threaded Insert Top Mount Opening | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 1 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 1 | Gold | M3 Threaded Insert Top Mount Opening | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder Wire Wrap | 1 | Gold | 4-40 Threaded Insert Top Mount Opening | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 1 | Gold | 4-40 Threaded Insert Top Mount Opening | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 1 | Gold | Flush Mount M3 Threaded Insert Top Opening | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 1 | Gold | Flush Mount Top Opening Unthreaded | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | 0.156 " | 3.96 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Wire Wrap | 1 | Gold | Flush Mount M3 Threaded Insert Top Opening | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 1 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Wire Wrap | 1 | Gold | 4-40 Threaded Insert Top Mount Opening | Cantilever | -40 C | 105 ░C | Female | 9 | Copper Alloy | Non Specified - Single Edge | 9 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.18 mm | 0.125 in | 0.25 Ám | 10 Áin | Black | Single | Card Guides |
