D6F-PH Series
Manufacturer: Omron Electronics Inc-EMC Div
Beta
⌘K
SENSOR 0.01PSID 0.16" 12BIT 4SIP
| Part | Port Size | Port Size [diameter] | Port Size [diameter] | Port Style | Accuracy | Features | Maximum Pressure | Maximum Pressure [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Supplier Device Package | Package / Case | Output Type | Output | Operating Pressure [Min] [x] | Operating Pressure [Max] [x] | Operating Pressure [Max] [x] | Operating Pressure [Min] [x] | Voltage - Supply [Min] | Voltage - Supply [Max] | Termination Style | Mounting Type | Pressure Type | Operating Pressure [custom] | Operating Pressure [custom] | Operating Pressure [Max] | Operating Pressure [Min] | Operating Pressure [Max] | Operating Pressure [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Electronics Inc-EMC Div | Dual Male Tube | 0.16 " | 4 mm | Barbless | 3 % | Temperature Compensated | 10 kPa | 1.45 PSI | -20 C | 80 C | 4-SIP | 4-SIP Dual Top Ports | I2C | 12 b | -1 PSI | 5 kPa | 1 PSI | -5 kPa | 2.3 V | 3.6 V | PC Pin | Through Hole | Differential | ||||||
 Omron Electronics Inc-EMC Div | Barbed | 3 % | Temperature Compensated | 10 kPa | 1.45 PSI | -20 C | 80 C | 4-SIP | 4-SIP Dual Top Ports | I2C | 12 b | 2.3 V | 3.6 V | PC Pin | Through Hole | Differential | 0.04 PSI | 0.25 kPa | |||||||||||
 Omron Electronics Inc-EMC Div | Barbed | 3 % | Temperature Compensated | 10 kPa | 1.45 PSI | -20 C | 80 C | 4-SIP | 4-SIP Dual Top Ports | I2C | 12 b | 2.3 V | 3.6 V | PC Pin | Through Hole | Differential | 0.04 PSI | 0.25 kPa | |||||||||||
 Omron Electronics Inc-EMC Div | Barbed | 3 % | Temperature Compensated | 10 kPa | 1.45 PSI | -20 C | 80 C | 4-SIP | 4-SIP Dual Top Ports | I2C | 12 b | -1 PSI | 5 kPa | 1 PSI | -5 kPa | 2.3 V | 3.6 V | PC Pin | Through Hole | Differential | |||||||||
 Omron Electronics Inc-EMC Div | Barbed | 3 % | Temperature Compensated | 10 kPa | 1.45 PSI | -20 C | 80 C | 4-SIP | 4-SIP Dual Top Ports | I2C | 12 b | 2.3 V | 3.6 V | PC Pin | Through Hole | Differential | 1 PSI | -1 kPa | 1 kPa | -1 PSI | |||||||||
Omron Electronics Inc-EMC Div | Dual Male Tube | 0.16 " | 4 mm | Barbless | 3 % | Temperature Compensated | 10 kPa | 1.45 PSI | -20 C | 80 C | 4-SIP | 4-SIP Dual Top Ports | I2C | 12 b | 2.3 V | 3.6 V | PC Pin | Through Hole | Differential | 1 PSI | -1 kPa | 1 kPa | -1 PSI | ||||||
Omron Electronics Inc-EMC Div | Dual Male Tube | 0.16 " | 4 mm | Barbless | 3 % | Temperature Compensated | 10 kPa | 1.45 PSI | -20 C | 80 C | 4-SIP | 4-SIP Dual Top Ports | I2C | 12 b | 2.3 V | 3.6 V | PC Pin | Through Hole | Differential | 0.04 PSI | 0.25 kPa |
