172-E25 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 25POS PNL MNT
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Contact Material | Wire Gauge [Min] | Wire Gauge [Max] | Color | Flange Feature | Number of Rows [custom] | Connector Style | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Contact Finish Thickness | Current Rating (Amps) | Number of Positions | Material Flammability Rating | Features | Contact Finish | Contact Type | Mounting Type | Connector Type | Shell Material, Finish [custom] | Shell Material, Finish [custom] | Termination | Shell Material, Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Brass | 19.5 AWG | 26 AWG | White | 4-40 | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Grounding Indents | Gold | Signal | Panel Mount | Plug Male Pins | ||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Glass Filled | White | Housing/Shell (Unthreaded) | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Gold | Signal | Panel Mount Through Hole | Plug Male Pins | Steel | Yellow Chromate Plated | Solder | |||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Brass | 19.5 AWG | 26 AWG | White | 4-40 | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Gold | Signal | Panel Mount | Receptacle Female Sockets | |||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Glass Filled | White | Board Side (4-40) | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Grounding Indents | Gold | Signal | Panel Mount Through Hole | Plug Male Pins | Solder | ||||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Brass | White | Cable Side (4-40) | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Grounding Indents | Gold | Signal | Panel Mount | Plug Male Pins | ||||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Brass | 19.5 AWG | 26 AWG | White | Cable Side (4-40) | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Grounding Indents | Gold | Signal | Panel Mount | Plug Male Pins | ||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Brass | 19.5 AWG | 26 AWG | White | Housing/Shell (Unthreaded) | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Grounding Indents | Gold | Signal | Panel Mount | Plug Male Pins | ||||
 NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) | Brass | 19.5 AWG | 26 AWG | White | 4-40 | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Gold | Signal | Panel Mount | Receptacle Female Sockets | Nickel Plated Steel | ||||
NorComp Inc. | 100 °C | -50 °C | Polybutylene Terephthalate (PBT) Glass Filled | White | Board Side (4-40) Mating Side Female Screwlock (4-40) | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Board Lock Grounding Indents | Gold | Signal | Panel Mount Through Hole | Plug Male Pins | Solder | ||||||
 NorComp Inc. | 100 °C | -50 °C | Polyamide (PA6T) Nylon 6T | Brass | White | Board Side (4-40) | 2 | D-Sub | B DB | 3 | Flash | 5 A | 25 | UL94 V-0 | Grounding Indents | Gold | Signal | Panel Mount Through Hole | Plug Male Pins | Solder | Nickel Plated Steel |
