391-013 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 13POS 0.100
| Part | Material - Insulation | Termination Rows | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Read Out | Number of Positions/Bay/Row | Number of Rows | Contact Type | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Color | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Card Type | Gender | Flange Feature | Termination | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | 4-40 Flush Mount Threaded Insert Top Opening | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | Floating Bobbin Flush Mount | Solder | 0.116 " | 2.95 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | 4-40 Flush Mount Threaded Insert Top Opening | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | Solder | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | Flush Mount Top Opening Unthreaded | Solder | 0.156 " | 3.96 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | Flush Mount M3 Threaded Insert Top Opening | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | Flush Mount Top Opening Unthreaded | Solder | 0.156 " | 3.96 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | Flush Mount M3 Threaded Insert Top Opening | Solder | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | Flush Mount Top Opening Unthreaded | Solder | 0.128 " | 3.25 mm |
 EDAC Inc. | Polyester Thermoplastic | 1 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Single | 13 | 1 | Semi Bellows | 13 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.1 " | 2.54 mm | Black | Through Hole | -40 C | 105 ░C | Non Specified - Single Edge | Female | Solder |
