896-044 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 44POS 0.125
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Termination | Contact Finish Thickness | Contact Finish Thickness | Card Type | Contact Material | Gender | Number of Rows | Color | Mounting Type | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Number of Positions | Termination Rows [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 44 | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Copper Alloy | Female | 1 | Black | Through Hole | Gold | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Single | 44 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 44 | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Copper Alloy | Female | 1 | Black | Through Hole | Gold | Flush Mount M3 Threaded Insert Top Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Single | 44 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 44 | Wire Wrap | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Copper Alloy | Female | 1 | Black | Through Hole | Gold | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Single | 44 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 44 | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Copper Alloy | Female | 1 | Black | Through Hole | Gold | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Single | 44 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 44 | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Copper Alloy | Female | 1 | Black | Through Hole | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Single | 44 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 44 | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Copper Alloy | Female | 1 | Black | Through Hole | Gold | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Single | 44 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | 44 | Solder | 0.25 Ám | 10 Áin | Non Specified - Single Edge | Copper Alloy | Female | 1 | Black | Through Hole | Gold | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Single | 44 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 22 | Solder | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female | Black | Through Hole | Gold | 4-40 Threaded Insert Top Mount Opening | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Dual | 44 | 2 | 2 | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 22 | Solder | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female | Black | Through Hole | Gold | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Dual | 44 | 2 | 2 | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 22 | Solder | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | Copper Alloy | Female | Black | Through Hole | Gold | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | 125 °C | -40 C | Dual | 44 | 2 | 2 |
