835-93 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN RCPT 66POS 0.1 GOLD PCB

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Contact Shape	Contact Material	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Pitch - Mating	Pitch - Mating	Contact Length - Post	Contact Length - Post	Contact Finish - Mating	Insulation Color	Termination	Mounting Type	Contact Finish - Post	Connector Type	Number of Rows [custom]	Material Flammability Rating	Contact Type	Fastening Type	Number of Positions	Insulation Height [z]	Insulation Height [z]	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating
Mill-Max Manufacturing Corp. 835-93-066-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	66	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
Mill-Max Manufacturing Corp. 835-93-064-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	64	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
Mill-Max Manufacturing Corp. 835-93-048-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	48	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
Mill-Max Manufacturing Corp. 835-93-014-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	14	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
Mill-Max Manufacturing Corp. 835-93-040-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	40	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
Mill-Max Manufacturing Corp. 835-93-026-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	26	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
Mill-Max Manufacturing Corp. 835-93-036-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	36	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
Mill-Max Manufacturing Corp. 835-93-024-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	24	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
Mill-Max Manufacturing Corp. 835-93-068-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	68 positions	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
Mill-Max Manufacturing Corp. 835-93-056-10-001000	200 µin	5.08 µm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	Circular	Beryllium Copper	0.1 in	2.54 mm	0.1 "	2.54 mm	2.03 mm	0.08 in	Gold	Black	Solder	Through Hole	Tin-Lead	Receptacle Pass Through	2	UL94 V-0	Female Socket	Push-Pull	56	0.13 in	3.3 mm	All	-55 C	125 °C	0.76 Ám	30 Áin
