780-M44 Series
Manufacturer: NorComp Inc.
Beta
⌘K
D SUB CONNECTOR, HD44, IP68, HIGH DENSITY, PLUG, SEAL-D 780-M SERIES, 44 CONTACTS, DB, SOLDER CUP
| Part | Dielectric Material | Color | Wire Gauge [Min] | Wire Gauge [Max] | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Material Flammability Rating | Contact Finish Thickness | Ingress Protection | Number of Rows [custom] | Current Rating (Amps) | Mounting Type | Contact Type | Shell Size, Connector Layout | Shell Material, Finish | Connector Style | Flange Feature | Features | Number of Positions | Connector Type | Contact Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Polybutylene Terephthalate (PBT) Glass Filled | Black | 24 AWG | 28 AWG | Brass | -55 C | 105 ░C | UL94 V-0 | Flash | IP67 - Dust Tight Waterproof | 3 | 3 A | Panel Mount | Signal | 3 | Nickel Plated Steel | D-Sub High Density | Housing/Shell (Unthreaded) | Grounding Indents | 44 | Plug Male Pins | Gold |
